Overland Storage SnapServer XSR 120 Instructions

Add-on/Spare PCIe Card Instructions
This document describes how to add or replace a PCIe card in a
SnapServer XSR 120 from Overland Storage.
WARNING:
To reduce the risk of electric shock or damage to
equipment, always remove any power cords while working
with the unit.
WARNUNG: Um das Risiko eines elektrischen Schlags oder
Schäden am Gerät zu vermeiden, ziehen Sie stets den
Netzstecker, bevor Sie an der Einheit arbeiten.
AVERTISSEMENT:
Pour réduire le risque de choc électrique
ou endommagement de l'équipement, retirez toujours les
cordons électriques en travaillant avec l'appareil.
CAUTION:
While working with the unit, observe standard
Electrostatic Discharge (ESD) precautions to prevent damage
to micro-circuitry or static-sensitive devices.

Register Add-on PCIe Card

NOTE: If you are only replacing an existing PCIe card, skip to the
next section, "Prepare the Unit."
When adding a PCIe card to your server, you must first
register it to activate the warranty. Technical and warranty
support are not available until this is done:
1. Go to the Overland Storage website
(http://www.overlandstorage.com/).
2. Select Service & Support > My Products.
3. At the Site Login, enter your e-mail address and
password, and click GO.
4. Click the Manage Products button.
5. From the Product Selector drop-down list, select the XSR
120 in which you are installing the PCIe card.
6. Click Add a Component.
7. Enter the PCIe card information.
8. Click Save & Exit.
IMPORTANT: Your warranty certificate will be emailed to you.
Follow the instructions included to complete the process.
10400577-001
©2014 Overland Storage, Inc.
SnapServer XSR 120™
Enter
Enter
5325301507-SnapServer XSR 120 s/n: 02
Page 1 of 4
