Ag Pro Plus HD
Owner's Manual & Parts Book
Grouser Products
755 2nd Ave NW - West Fargo, ND 58078
Phone: 1-800-747-6182
Fax: 1-701-282-8131
E-mail: grouser@grouser.com
Website: www.grouser.com
PN: 42414
Serial Number: 10206071-Current
Purchase Date
Serial Number
Model Number
Tractor Model
Dealer
Date 3-25-2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ag Pro Plus HD and is the answer not in the manual?

Questions and answers

Related Manuals for Grouser Products Ag Pro Plus HD

Summary of Contents for Grouser Products Ag Pro Plus HD

  • Page 1 Ag Pro Plus HD Owner’s Manual & Parts Book Purchase Date Grouser Products Serial Number 755 2nd Ave NW - West Fargo, ND 58078 Model Number Phone: 1-800-747-6182 Fax: 1-701-282-8131 Tractor Model E-mail: grouser@grouser.com Dealer Website: www.grouser.com PN: 42414 Serial Number: 10206071-Current...
  • Page 2 Contact Us, Improvements, & Warranty Thank you for your recent purchase of a Grouser Ag Pro Plus HD Dozer. Welcome to the family of satisfied Grouser blade owners. Grouser Products is committed to offering quality products to help professionals in their daily jobs. We are also committed to providing you the highest level of customer satisfaction possible.
  • Page 3 The Ag Pro Plus HD Dozer: 1. The Ag Pro Plus HD Dozer should be operated only by those who are responsible and instructed to do so. 2. Read the owner’s manual carefully before using this equipment. Lack of operating knowledge can lead to accidents.
  • Page 4 ITEM ITEM QTY. PART NO. DESCRIPTION QTY. PART NO. DESCRIPTION 11-40760-L Ag Pro Plus Manual Pitch Top Arm Assy 43-14725 Lift Frame / UC Pin 11-40760-R Ag Pro Plus Manual Pitch Top Arm Assy 43-18120 Top Pin Weld 43-18127 Top Arm Pin Weld 16-20002 1/4"...
  • Page 5 Some assembly of Lift System components is necessary. Follow the steps listed below. See diagram below for the correct hardware and orientation of parts. 1. Remove all pins and fasteners on each side of the undercarriage and set aside for later installation. 2.
  • Page 6 ITEM QTY. PART NO. DESCRIPTION 16-18957 5/16” x 3-1/4” Allen Head Screw 25-19861 Multi-Coupling Plate - 5 Port - Fixed 25-19863 Multi-Coupling Plate - 5 Port - Cap 25-19870 Multi-Coupling Plate - Male Coupler 25-3401 Pioneer Dust Cap Left Angle (Yellow) 25-34342 Tappet Quick Coupler Male - Poppet Style 25-3453...
  • Page 7 ITEM QTY. PART NO. DESCRIPTION 34-18888-RD -12 Red - Spiral Band 34-18888-YL -12 Yellow - Spiral Band 34-19494-OR -16 Orange - Spiral Band 35-12631-0350 35" x 1/2" -8JIC / -8JIC Abrasion Resistant Hose 35-12631-0780 78” x 1/2" -8JIC/-8JIC Abrasion Resistant Hose 35-12631-0810 81”...

  • Page 8: Tilt Function

    15. Cycle the left cylinder in and out 5 more times and then the right cylinder in and out 5 more times. 16. Check tractor oil level and fill if necessary. Run the blade through all the functions. If any function does not operate correctly, refer to corresponding section above and re- bleed. If problem still persists, call Grouser Products.
  • Page 9 With the Electric Hydraulic Angle Option, you will have the ability to angle the blade 30 degrees left or right. To achieve these angles, the two cylinders are designed to operate independently of each other through an electric diverter valve. To angle the blade to the left, actuate the tractor hydraulic control lever in the cab with the diverter valve un-powered.
  • Page 10 To Connect: Note: If necessary, use a spotter to help center the blade on the lift system. 1. Before standing blade upright for initial connection, remove the 3/4” pin (#20 on Page 12) so the skid shoes can move freely. The blade will lean back further for easier connection.

  • Page 11: Skid Shoe Adjustment

    Skid Shoe Adjustment: 1. Remove the handle from the ratchet keeper by pulling the hitch clip pin and insert it into the handle receiver on the ratchet jack. 2. Loosen the locking nut on the ratchet jack. Storage 3. Hold the body of the ratchet jack and rotate the ratchet jack Location handle to raise or lower the skid shoes.
  • Page 12 ITEM NO. PART NO. 14'/QTY. 16'/QTY. 18'/QTY. DESCRIPTION 15-19110-14 HD Blade Weld 15-19110-16 HD Blade Weld 15-19110-18 HD Blade Weld 15-18520-14 Top Extension Weld 15-18520-16 Top Extension Weld 15-18520-18 Top Extension Weld 16-18945 1" x 3" Hex Bolt Gr 5 NC - Short Thread 16-20538 7/8"...
  • Page 13 4,5,6 1,2,3 Item #36 for Ag Pro Dozer Name Plate and Item #35 for Custom Name Plate ITEM NO. PART NO. 14'/QTY. 16'/QTY. 18'/QTY. DESCRIPTION 27-40951 Classic Decal 27-40962 Warning Prop 65 Decal 29-11118-6 6' - 3/4”x 8” Cutting Edge 29-11118-7 7' - 3/4”x 8”...
  • Page 14 ITEM NO. QTY. PART NO. DESCRIPTION 11-12397 Stabilizer Arm 11-19685 Angle Arm Assembly-R 11-19690 Angle Arm Assembly-L 11-40866 Bell Crank 16-20011 1/4" x 2-3/4" Hex Bolt Gr 5 NC 16-20130 1/2" x 2-1/2" Hex Bolt Gr 5 NC 16-20132 1/2" x 3" Hex Bolt Gr 8 NC 16-20424 1/2"...
  • Page 15 ITEM NO. QTY. PART NO. DESCRIPTION 32-18265 HA Tilt Frame 32-19675 Angle Frame 34-17799 Latch Spring 39-14663 Latch 39-14665 Handle Weld 39-3072 Rubber Handle 43-18486 AG Pro SS QA Lock Pin 43-8130 1-15/16" X 23-1/4" NR Pin 43-8131 1-15/16" X 31" NR Pin 43-8132 1-15/16"...
  • Page 16 ITEM NO. QTY. PART NO. DESCRIPTION DETAIL A 16-20034 5/16" x 1" Hex Bolt Gr 5 NC 16-20035 5/16" x 1-1/4" Hex Bolt Gr. 5 16-20037 5/16" x 2" Hex Bolt Gr 5 NC 16-20040 5/16" x 2-1/2" Hex Bolt Gr 5 NC 16-20220 3/4"...
  • Page 17 ITEM NO. QTY. PART NO. DESCRIPTION 31-34040 Straight JIC x O-Ring DETAIL B 31-34050 Straight Thread Elbow 90° JIC x O-Ring 31-34060 Branch Tee JIC x O-Ring 31-34070 Run Tee JIC x O-Ring 31-34080 Swivel Nut Branch Tee JIC 31-34100 Swivel Nut Elbow 90°...
  • Page 18 Before Each Use: Fixed Half Mobile Half Disconnect the mobile half from the parking station and the cap from the fixed half. Check that there is no contamination (salt, sand, dirt, etc.): On the pins. Inside the cam. In the locking mechanism area. On the face of the plates and couplings.
  • Page 19 Cleaning The Male Interface Seal Cleaning The Female Bushing: Make sure the coupling is securely fastened Make sure the coupling is securely fastened into the plate or place in a vice. into the plate or place in a vice. Using a blunt, non-marring tool, depress the Using a non-marring tool, depress the valve face until the seal is exposed.
  • Page 20 Page Left Blank Intentionally...
  • Page 21 Colored Lines = Quantity of Colored Spiral Bands Tilt Cylinder Tilt Cylinder Angle Cylinder Left Angle Cylinder Right Hydraulic Multi-Couplers Left Right Lift Cylinder Lift Cylinder Left Left Right Right Tilt Right Tilt Left Lift Up Lift Down Angle Angle Side Up Side Up Angle Angle...
  • Page 22 Page Left Blank Intentionally...
  • Page 23 Page Left Blank Intentionally...

  • Page 24: Warranty

    Contact Us As always, if you have any questions about your Ag Pro Plus HD Dozer or other products made by Grouser, feel free to contact us. Grouser Products 755 2nd Ave NW - West Fargo, ND 58078 Phone: 1-800-747-6182 Fax: 1-701-282-8131 E-mail: grouser@grouser.com...
