3. Connections and indicators
Signal
Terminal
strip
BUZZER
LED
D0
D1
Left
GND
GND
AC / DC +
AC
OPEN
NO
COM
Right
NC
V OUT
IR
Operation
Stand-by
Programming mode start
Programming command start
Error
End programming mode
Opening
ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C
08172 Sant Cugat del Vallés · Barcelona (Spain)
Phone: +34935839543 · info@ek.plus · www.ek.plus
Type
Tone indicator to the card reader
Output
Output
Led indicator of the card reader
Entrada
Data[0] reception from the card reader
Data[1] reception from the card reader
Entrada
Entrada /
Ground (Connection to the card reader)
Output
Entrada /
Ground (DC Voltage feeding)
Output
Entrada
Common connector for AC or DC power (positive)
Connector for AC voltage feeding
Entrada
Entrada
Connect to the external push button (Optional)
Relay output (Normally open)
Output
In "Dry Contact" configuration (Position A): Common
Port
Output
In "DC Out" configuration (Position B): Ground
Connect to external push button (optional)
Output
Relay output (Normally closed)
Output
Voltage for feeding the card reader
Input
IR sensor for remote control
Output
LED
Red
Blinking red
Orange
-
Red
Green
