1. Overview

The access controller, CCA, allows the opening of all types of door openers once an authorized
RFID card has been read. The reading is performed by an external reader connected to the
controller (Ref. LCA). The controller is compatible with several input voltages. It allows to control the
voltage pass that feeds the current lock or use the power supply of the controller to power the lock.
Thanks to all these compatibilities the controller can be coupled to existing systems or installed in
new scenarios.
The programming of user cards can be done through the use of other cards (called master) or
through a remote control. It is important to note that, through remote control, other functions can be
performed such as setting the opening time, deleting and registering cards selectively, activating or
deactivating the sound or LED indicators, ... Master cards provide simplicity when registering user
cards.
There is no distinction between cards except their programming; For example, a master card could
be programmed as a user card. As explained below, it is important to identify each user card with
an identifying number.Permite alimentar varios tipos de cerradura (AC/DC) con la propia tensión
que alimenta a la controladora.
•
It allows to feed several types of lock (AC / DC) with the own voltage that feeds the controller
•
It allows to control the voltage that feeds the lock from an external source, either AC or DC
•
Allows the connection of a button (push button) for instant door opening
•
Users registered in a controller can be cloned in other controllers
•
Supports up to 1000 users
•
Compatible with Wiegand readers
•
Allows management by remote control

2. Accessories

•
1x Remote control (keyboard)
•
1x Master card to add users
•
1x Master card to remove users
•
1x Configuration jumper
•
1x Protection diode
•
1x Screwdriver
•
2x Anchors and screws
•
1x Installation Manual
