- Page 1 ACCESS CONTROL DOOR PHONES PanDoor PSTN Line adaptive Door Access Control Device Installation and Programming Manual...
- Page 2 PanDoor Installation and Programming Manual Version 1, Release 1.4, August 2008...
- Page 4 NOTICE This manual describes the PanDoor Access Control Door Phone system. Additional copies of this manual may be obtained from ITS. No part of this document may be reproduced or transmitted in any form, by any means (electronic, photocopying, recording, or otherwise) without the prior written permission of ITS.
-
Page 5: Table Of Contents
Table of Contents Introduction ............1 Product Description..........1 Schematic Setup ............ 3 Operating Methods..........4 Installation............7 Installing the PanDoor Wall Bracket..... 7 Installing the PanDoor Panel......... 8 Installing the Controller ........10 LED Indications ..........12 Programming ............14 Programming Code Guide........15 Troubleshooting ..........19... -
Page 6: Introduction
Introduction 1 Introduction ITS is pleased to introduce PanDoor, the latest addition to the wide range of indoor and outdoor Access Control Door Phones, which provides a cutting-edge technology, a high quality hands- free telephone and a built-in electromagnetic lock relay, alongside with an easy set-up, durable design and “plug and play”... - Page 7 Introduction Camera (optional) Speaker Keypad (optional) Calling Button Microphone Figure 1. PanDoor Panel PanDoor Installation and Programming Manual...
-
Page 8: Schematic Setup
Introduction Schematic Setup The following picture illustrates the schematic setup of the PanDoor system. Figure 2. PanDoor Schematic Setup PanDoor Installation and Programming Manual... -
Page 9: Operating Methods
Introduction Operating Methods There are three methods of opening the door using the PanDoor panel: • Opening the door from the outside. To open the door from the outside, you must dial a pre-defined code on the outdoor unit keypad. When the code is entered correctly, the keypad light flashes, and the door opens. - Page 10 Introduction Figure 3. Ring Cycle PanDoor Installation and Programming Manual...
- Page 11 Introduction This page is intentionally left blank PanDoor Installation and Programming Manual...
-
Page 12: Installation
Installation 2 Installation The PanDoor should be mounted on the supplied installation bracket as displayed in Figure 4. Figure 4. Outdoor Unit Bracket Warning DO NOT ROUTE TELEPHONE AND AC WIRING INSIDE THE SAME CONDUIT. Route all telephone wires inside a dedicated conduit that is at least six inches away from any AC line wiring. -
Page 13: Installing The Pandoor Panel
Installation Installing the PanDoor Panel You can connect either one or two outdoor PanDoor units to a single controller (indoor unit). The PanDoor can be connected to an external bypass switch for opening the door lock. This switch can be installed inside the residence and should be connected to the SW and /SW terminals on the PanDoor wire connector. - Page 14 Installation +12V 12VDC power input from controller -12V Normally open/closed N.O. outputs (external device) N.C. Door lock relay terminals -DLR /DLR Switch terminals CCTV+ Camera power output CCTV- RING Figure 5. Outdoor Panel Wire Connector PanDoor Installation and Programming Manual...
-
Page 15: Installing The Controller
Installation To install the PanDoor Panel: 1. Remove the PanDoor panel cover and locate the wire connector. 2. Connect the 12V wires from the controller to the +12V and -12V terminals. 3. Connect the audio wires from the controller to the TIP and RING terminals. - Page 16 RING 12VDC output to KEYPAD 1 keypad 1 panel POWER 12VDC output to KEYPAD 2 keypad 2 panel POWER 12V battery input BATTERY (optional) 13.8V charger input CHARGER (optional) Figure 6. Controller Unit Wire Connector PanDoor Installation and Programming Manual...
-
Page 17: Led Indications
The door panels are equipped with three green LEDs located between the keypad and panel body, as displayed in Figure 7. When inactive, these LEDs are invisible, but when activated their emitted light is clearly visible. PanDoor Installation and Programming Manual... - Page 18 LED 3 Idle First touch on keypad Code error Fast Blink Fast Blink Fast Blink Door open Slow Blink Slow Blink Slow Blink Timeout to return to idle state: 10 seconds after last digit was pressed. PanDoor Installation and Programming Manual...
-
Page 19: Programming
Programming 3 Programming PanDoor programming is performed via a telephone using DTMF commands. Operational keys: Operation Command Comment Connect to panel #1 – connect to panel 1 #2 – connect to panel 2 Connect to #9 – connect to Use this option for... -
Page 20: Programming Code Guide
Default Access code *110 + XX + YYY…+# 00=9876 where: Unit: XX = Access code number (00-99) Panel YYY…= New Access code (2-6 digits) Note: The capacity of access codes is 100 entries per panel. PanDoor Installation and Programming Manual... - Page 21 “Relay activation” (*150) Controller Conversation timeout *200 + XX where: Unit: XX = Seconds (10-99) 00 = Unlimited Panel Door opening time *250 + X 3 sec limit (sec) X = Seconds (1-9) Unit: Panel PanDoor Installation and Programming Manual...
- Page 22 Example: 2.5 sec pause = Unit: 2500 msec parameter (PSTN ring silence) Panel Number of rings in *363 +XXXX + # the cycle where: XXXX = Digits (0-9) Unit: Example: 0025 PSTN ring Minimum value: 0003 Panel PanDoor Installation and Programming Manual...
- Page 23 Note: Up to 4 digits Unit: Panel Change the system *600 + New password 1234 administrator’s (must be 4 digit long). password (for programming) Note: Do not use the * or # keys. Unit: Controller PanDoor Installation and Programming Manual...
-
Page 24: Troubleshooting
PSTN to panel and PSTN) you need to dial the PSTN/Panel opening the door, I switching digit (default=0). cannot return to the It is possible that the person on the PSTN PSTN call. line disconnected the conversation. PanDoor Installation and Programming Manual... - Page 25 When set to =0, camera is disabled. When set to =2, camera will be activated only during call or panel touch. Check cables wiring. Make sure your video equipment is compatible to the camera. Consult the technical specification section for details. PanDoor Installation and Programming Manual...
-
Page 26: Specifications
>40msec Inter-Digit Pause Time >40msec Tone Burst Length <2A Relay Switching Current Dimensions (HxWxD): 219x122x23mm/8.6x4.8x0.9inch Outdoor Unit 185x95x38mm/7.3x3.7x1.5inch Controller Outdoor: -20º to 50ºC/ Operating Temperature 4º to 122ºF Indoor: 0º to +35ºC/ 32º to 95ºF PanDoor Installation and Programming Manual... -
Page 27: Camera Specifications
Minimum Illumination 1/50–1/100,000 sec Electronic Shutter Better than 48dB S/N Ratio 1.0Vp-p composite video Video Signal Output signal @75Ω load 0.45 Gamma Correction Auto Gain Control (AGC) Gain Control 5.5mm F5.5/60° Lens & View Angle PanDoor Installation and Programming Manual... - Page 28 White Balance (zero color rolling) AWB/ATW: 3200–10000°K White Balance Range FIX: 3200°K 1/50–1/120,000 sec Electronic Shutter 1.0Vp-p composite video Video Output signal @75Ω load 0.45 Gamma Correction Gain Control 45° > 0.7mm Lens & View Angle PanDoor Installation and Programming Manual...
