1. General description

The access controller, CCA, allows the opening of all types of door openers once an authorized RFID card has been
read. The reading is performed by an external reader connected to the controller (Ref. LCA). The controller is
compatible with several input voltages. It allows to control the voltage pass that feeds the current lock or use the
power supply of the controller to power the lock. Thanks to all these compatibilities the controller can be coupled
to existing systems or installed in new scenarios.
The programming of user cards can be done through the use of other cards (called master) or through a remote
control. It is important to note that, through remote control, other functions can be performed such as setting the
opening time, deleting and registering cards selectively, activating or deactivating the sound or LED indicators, ...
Master cards provide simplicity when registering user cards.
There is no distinction between cards except their programming; For example, a master card could be
programmed as a user card. As explained below, it is important to identify each user card with an identifying
number.
•
It allows to feed several types of lock (AC / DC) with the own voltage that feeds the controller
•
It allows to control the voltage that feeds the lock from an external source, either AC or DC
•
Allows the connection of a button (push button) for instant door opening
•
Users registered in a controller can be cloned in other controllers
•
Supports up to 1000 users
•
Compatible with Wiegand readers
•
Allows management by remote control
2. Accessories
• 1x Remote control (keyboard)
• 1x Master card to add users
• 1x Master card to remove users
• 1x Configuration jumper
• 1x Protection diode
• 1x Screwdriver
• 2x Anchors and screws
• 1x Installation Manual

3. Connections and indicators

Signal Terminal
strip
BUZZER
LED
D0
D1
Left
GND
GND
AC / DC +
AC
OPEN
NO
COM
Right
NC
V OUT
IR
Type
Output
Tone indicator to the card reader
Output Led indicator of the card reader
Entrada Data[0] reception from the card reader
Entrada
Data[1] reception from the card reader
Entrada / Output Ground (Connection to the card reader)
Entrada / Output Ground (DC Voltage feeding)
Entrada Common connector for AC or DC power (positive)
Entrada Connector for AC voltage feeding
Entrada Connect to the external push button (Optional)
Output Relay output (Normally open)
In "Dry Contact" configuration (Position A): Common Port
Output In "DC Out" configuration (Position B): Ground
Connect to external push button (optional)
Output Relay output (Normally closed)
Output Voltage for feeding the card reader
Input IR sensor for remote control
Output Status LED indicator
1
Description
