- Page 1 370001 Access controller Installation manual...
-
Page 2: General Description
1. General description The access controller, CCA, allows the opening of all types of door openers once an authorized RFID card has been read. The reading is performed by an external reader connected to the controller (Ref. LCA). The controller is compatible with several input voltages. - Page 3 Operation Sound Stand-by Programming mode start Blinking red One bip Programming command start Orange Two bips Error Three bips End programming mode One bip Opening Green One bip 4. Input and output voltage The controller supports a wide range of supply voltage, both in AC or DC. The self-lock power supply can be used to feed the controller.
-
Page 4: Installation
A-Position (Dry contact) B-Position (Input pass) Terminals COM-NC COM-NO COM-NC COM-NO Same voltage as Stand-by Short circuit Open circuit in the input Same voltage as Opening Open circuit Short circuit in the input Open the device and adjust the jumpers depending on your needs. Attention: Install the supplied diode directly in the door opener in the case that it supplies the lock with direct voltage -DC. - Page 5 6. Programming & Users management The programming of the cards is stored in the memory of the device so the system is robust in the event of power supply drops. In the absence of power supply the controller will not be able to activate the door opening, as it will not read the cards.
- Page 6 6.2.2. User management (via remote control) Each user card is registered with an identifier that matches its position within the system. The controller can assign auto-incremented identifiers. You can also assign a specific identifier. Subscribing: To add user cards at a position given by the system: Step 1 Enter in the programming mode * <Master code>...
- Page 7 6.2.4. Control signals (via remote control) It is possible to enable / disable basic signalling indicators. By default, those are enabled. Step 1 Enter in the programming mode * <Master code> # Step 2A Indication sound 70# OFF 71# ON Step 2B Led indication 74# OFF...
- Page 8 Step 1 Power off the controller Make a short circuit between GND and OPEN. Step 2 Otherwise, should a push button be connected (for opening purposes), keep it pressed. Two sounds will be heard Power on the system again and the LED will change its Step 3 colour After each card...
-
Page 9: Technical Specifications
7. Technical specifications REFERENCE Code 037001 Maximum users <1000 Transmisson protocol card reader – controller Wiegand Working voltage / (Nominal) V (rms) 12~30 / (24) 9~24 / (12) Consumption (Stand-by / Maximum*) AC mA (rms) 115 / 170 60 / 80 Output voltage (For LCA) Maximum switching current Maximum distance IR- Keyboard **...
