6.3. Programming via master cards

By using the master cards it is possible to subscribe / unsubscribe user cards, without need to use the
remote control.
This method does not allow to delete a user card that has been lost, even knowing its identifier.

6.3.1. Registering master cards

The master cards need also to be paired to the system. Should a second pair of master cards is
registered, the first will be unregistered. The master cards, cannot be programmed via keyboard.
Step 1 Power off the controller
Make a short circuit between GND and OPEN.
Step 2
Otherwise, should a push button be connected
(for opening purposes), keep it pressed
Step 3 Power on the system again
Step 4 Present the two cards on the card reader. The
first will be coded as "MASTER ADD" (For
subscribing). The second, will be "MASTER
Step 5 Remove the bridge
Master cards cannot be programmed by keyboard.

6.3.2. Management of user cards using master cards

To add user cards, perform this process on the reader:
Step 1
Step 2
Step 3
ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C
08172 Sant Cugat del Vallés · Barcelona (Spain)
Phone: +34935839543 · info@ek.plus · www.ek.plus
DELTE" (For unsubscribing).
Sweep MASTER ADD card
Sweep the user card
Sweep MASTER ADD card
USER MANUAL CCA
Two sounds will be heard and
the LED will change its colour
After each card presentation, a
single sound will be heard.
After presenting the second
card, the system will enter in
stand-by mode.
If any card is presented within
10 seconds, the system will
enter in stand-by mode.
More user cards may be swept (A
sound will be heard)
15
