Phoenix 5 Shelf
Assembly Instructions
Dimensions
Width - 70cm
Depth - 35.5cm
Height - 175cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
Please keep for future reference
-
-
314/9449
352/4600
Version 1 Date: 20/10/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argos Phoenix 314/9449
Summary of Contents for Argos Phoenix 314/9449
- Page 1 Width - 70cm Depth - 35.5cm Height - 175cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Version 1 Date: 20/10/14...
- Page 2 IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE • Argos Ltd. MK9 2 NW. • This product is intended for • Assembly of this product must children in the age range of be carried out by a competent 7-12 years.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Top / Bottom panel x 2 Shelf x 4 (69.9 x 34.9cm) (66.8 x 34.9cm) Right / Left side panel x 2 (171.6 x 34.9cm)
- Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. 30mm Dowel x 16 50mm Screw x 24 Screw cover x 24 Nail x 44...
- Page 5 Assembly Instructions Step 1 Fitting dowels and screws Insert Dowels into the Shelf Fasten Screws(8 pcs) by Allen key to fix Unfinished back edge Right / Left side panel onto the Shelves Use Screw covers cover the screw heads. Fasten Screws(8 pcs) by Allen key to fix Right / Left side panel...
- Page 6 Assembly Instructions Step 2 Attaching top and bottom panels Unfinished Fasten Screws(8 pcs) back edge by Allen key to fix Top / Bottom panel onto the unit. Use Screw covers Unfinished cover the screw heads. back edge Step 3 Fixing back panel Attach Top back panel and Bottom back panel Unfinished...
- Page 7 Warning: Before drilling, check wall for hidden pipes and cables. Reposition the unit and fix wall strap using Screw Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
- Page 8 A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
