- Page 1 ThermoSpot S p o t T h e r m o Laser 650 nm Laser-Focus 12 m 12:1...
- Page 2 Read the operating instructions and the enclosed brochure „Guarantee and additional notices“ completely. Follow the instructions they contain. This document must be kept in a safe place and if the laser device is passed on, this document must be passed on with it. General safety instructions Laser radiation! Do not stare into the beam!
- Page 3 ThermoSpot Laser beam switched on Battery charge Hold function Measured value display Max. value during the measurement Display lighting Unit of measurement °C / °F °C / °F To set the required temperature unit, press and hold the „°C/°F“ button until...
- Page 4 Measurement procedure notice This infrared temperature instrument detects the temperature of various surfaces and materials. A built-in sensor head detects the material-specific infrared rays emitted by every object. The amount of these emissions is determined by the material‘s emission coefficient (0 ... 1). This instrument is permanently set to an emission coefficient of 0.95, which is applicable to most organic materials as well as plastics, ceramics, wood, rubber and stone.
-
Page 5: Technical Data
ThermoSpot Technical data Technical revisions reserved. 06.15 Measurement range -38 °C … 365 °C (-36.4 °F … 689 °F) ± 2.5 °C + 0.05 °C / degree (-38 °C … 0 °C) Accuracy ± 2.5 °C (0 °C … 365 °C) or ±... - Page 6 ThermoSpot SERVICE Umarex GmbH & Co KG – Laserliner – Möhnestraße 149, 59755 Arnsberg, Germany Tel.: +49 2932 638-300, Fax: +49 2932 638-333 laserliner@umarex.de Umarex GmbH & Co KG Donnerfeld 2 59757 Arnsberg, Germany Tel.: +49 2932 638-300, Fax: -333...
