AutoCross-Laser ACL 4P RX
Bedienungsanleitung
D
Operating instructions
GB
Gebruiksaanwijzing
NL
Betjeningsvejledning
DK
Mode d´emploi
F
Instrucciones para su uso
E
Istruzioni d'uso
I
Instrukcja Obsługi
PL
Käyttöohje
FIN
Instruções de uso
P
max.
50 m
3-8
9-14
15-20
21-26
27-32
33-38
39-44
45-50
51-56
57-62

Advertisement

loading

Related Manuals for LaserLiner AutoCross-Laser ACL 4P RX

Summary of Contents for LaserLiner AutoCross-Laser ACL 4P RX

  • Page 1 AutoCross-Laser ACL 4P RX max. 50 m Bedienungsanleitung 9-14 Operating instructions 15-20 Gebruiksaanwijzing 21-26 Betjeningsvejledning 27-32 Mode d´emploi 33-38 Instrucciones para su uso 39-44 Istruzioni d'uso 45-50 Instrukcja Obsługi 51-56 Käyttöohje 57-62 Instruções de uso...
  • Page 2 AutoCross-Laser ACL 4P RX...

  • Page 3: Warranty

    AutoCross-Laser ACL 4P RX The universal cross-line laser with Laserreceiver The cross-line laser with 4 line lasers and additional plumb laser, 635 nm. With the laser receiver, the laser lines can be seen in any light – so ideal for all indoor and outdoor applications.
  • Page 4 AutoCross-Laser ACL 4P RX Windows for line lasers ON / OFF switch Transport securing device Knob for precision adjustment 5/8” thread (underside) Window for plumb laser (underside) Adjustable feet Tripod adapter Round vial for rough adjustment Socket for power supply (6V)
  • Page 5 AutoCross-Laser ACL 4P RX A Power indicator B Switch accuracy short range / long range C LED for accuracy green / red D ON / OFF switch E Sound ON / OFF F Receiver field for laser beam G LED’s for Laserindication (front,...

  • Page 6: Universal Mount

    AutoCross-Laser ACL 4P RX Working with the laser receiver RX 50: For levelling over longer distances or in conditions of bright light, use the laser receiver RX 50. Switch on with button D; control lamp A will light IMPORTANT: Set the ACL 4P RX to hand receiver mode (button 13).
  • Page 7 AutoCross-Laser ACL 4P RX Note: Regularly check the calibration before use, after transport and after extended periods of storage. Technical data Self-levelling range + 3° Precision + 2 mm / 10 m Working range with laser receiver max. 50 m...
  • Page 8 AutoCross-Laser ACL 4P RX Preparing the calibration check: It is possible for you to check the calibration of the laser. To do this, position the device midway between 2 walls, which must be at least 5 metres apart. Switch the device on (Laser cross ON). The best calibration results are achie- ved if the device is mounted on a tripod.
  • Page 9 AutoCross-Laser ACL 4P RX Zubehör (optional) Accesorios (opcional) Accessories (optional) Accessori (optional) Akcesoria (opcja) Accessoires (optioneel) Lisämahdollisuuksia Tilbehør (flere typer) valinnaisvarusteilla Accessoires (en option) Acessórios (opcional) Art.-Nr: 023.61A Art.-Nr: 090.120 Art.-Nr: 080.30 75° www.laserliner.com...
  • Page 10 AutoCross-Laser ACL 4P RX LASERSTRAHLUNG NICHT IN DEN STRAHL BLICKEN! LASER KLASSE 2 M EN60825-1:2003-10 Service- und Versand-Anschrift: Dirección de envío y de servicio Service-Telefon +49 2932 638-486 post-venta: +49 2932 638-489 Telefon: +49 2932 638-300 +49 2932 638-333 Service- and Shipping Address:...
