Summary of Contents for LaserLiner MultiBeam-Laser 5
- Page 1 MultiBeam-Laser...
- Page 2 MultiBeam-Laser...
- Page 3 Umarex-Laserliner. Note: This product is a precision instrument that must be handled and treated with care.
- Page 4 13 Slot for tightning belt Battery replacement Make sure the batteries are correctly poled! Switch on Assemble with connecting screw (11) MultiBeam-Laser 5 and magnetic base. Switch the unit on (5). The laserdots will be projected. Applications (examples see P. 2) A Aligning...
-
Page 5: Technical Data
MultiBeam-Laser Case dimensions – laserbeams Z-axis Measures in mm Technical Data Automatic levelling side-side + 4° range forward-backward + 6° Accuracy + 2 mm / 10 m Operating range ca. 100 m (depending on room illumination) 3 x 1,5V AA / Power supply ca. - Page 6 MultiBeam-Laser Preparing the calibration check It is possible for you to check the calibration of the laser. To do this, position the device midway between 2 walls, which must be at least 5 metre apart. Switch the device on. The best calibration results are achieved if the device is mounted on a tripod.
