Garden Party
10ft X 10ft
™
9ft 9in Wide x 9ft 9in Deep x 6ft3in Side Height /
9ft7in Center Height
King Canopy Item #: GP1010
With 4 Legs, Foot Pads, Cover & Screens.
WARNING:
Keep all flame and heat sources
away from this tent fabric. Meets
the flammability requirements of
CPAI-84. It is not fire proof. The fabric
Distributed by:
will burn if left in continuous contact
PIC America, LTD.
with any flame source.
1730 Five Points Lane • Fuquay-Varina, NC 27526
1-800-800-6296 • www.kingcanopy.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KING CANOPY Garden Party GP1010
Summary of Contents for KING CANOPY Garden Party GP1010
- Page 1 10ft X 10ft ™ 9ft 9in Wide x 9ft 9in Deep x 6ft3in Side Height / 9ft7in Center Height King Canopy Item #: GP1010 With 4 Legs, Foot Pads, Cover & Screens. WARNING: Keep all flame and heat sources away from this tent fabric. Meets the flammability requirements of CPAI-84.
- Page 2 PARTS LIST 6X6PC (12) 78” Pipe 1 3/8” 3X2PC (4) 38” Swedge Pipe 1 3/8” 4WCPC (4) 4-Way Fittings 1 3/8” FOOTPC (4) Metal Foot Pads 1 3/8” TOPPC (2) 2 Piece White Powder Coated Fitting GPT10 G, A or R (1) 100% Polyester Cover with Screens Cover Comes With 32 Curtain Rings For The Screens...
- Page 3 FRAME ASSEMBLY 1. Arrange all pipes and fittings on the ground as in Figure #1. 2. Insert one swaged pipe into one long straight pipe. This extended pipe will be inserted into each of the corner fittings to form the length of the sides. Insert long pipe into each of the corner fittings to form roof supports.
- Page 4 SCREEN ASSEMBLY 1. Position screens on outside of the leg poles with the elastic ties facing out (Figure #1). Screens attach to the top frame like shower curtains using the included rings. (Figure #2) Figure #1 Figure #2 2. Tie the strap around the corner fitting at the top. (Inset Figure #2)
- Page 5 SCREEN ASSEMBLY 3. Attach the screens to the leg poles with the elastic ties as shown (Figure #3). Figure #3 4. Now you can either zipper the screens together or tie the screens back by securing the elastic tie strap around the screens and attaching them to the ties that are holding the screen walls at the legs.
- Page 6 ANCHORING YOUR UNIT This canopy is designed for use as a temporary structure. After assembly, the canopy MUST BE securely anchored to the ground to prevent damage from winds. Your canopy will act like a kite in the wind if not properly and securely anchored to the ground.
- Page 7 IMPORTANT NOTICE: PLEASE READ CAREFULLY We are confident that you will be completely satisfied with your King Canopy unit. Please take a moment to read the very important information below, and call us with any questions you may have. King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and we are in no way responsible for any damage caused by the canopy or to the canopy.
- Page 8 Improper Anchoring, Strong Winds, Rain Snow, or Ice King Canopy/PIC America, LTD. does not guarantee these canopies under strong weather conditions. These canopies are designed to protect against damages caused by sun, rain, tree sap, birds, etc. They are not designed to hold roof loads that accompany snow, ice or heavy rains.
