Remote RS232 Interface

D9 female connector from rear panel is used for selecting the switcher through RS232
interface.
The pin configurations are:
D-9 Male
3
5
The simple command used for selecting the channels is
Input Channel
Channel 1
Channel 2
:
:
Channel 8
Communication parameters are 9600 baud, 8-bit, 1 stop bit and no parity.
B. Scanning Mode: (Auto Switching):
For scanning mode, keep slide-switch in scan position on back panel. Scanning time for
each channel is 5 seconds.
In scan mode scanning of all Video inputs are done regardless of the PCs are ON or
OFF.
Please check earthing before installing the switcher to avoid ghost images and flickering &
communication port problems
Decimal
1!
2!
:
:
8!
4
Phone: 91-79-55310266 / 55124898 (M) 0-98253-50221
www.interfaceproducts.info
Channels
RX
GRD
ASCII
31, 21
32, 21
:
:
38, 21
