Operation - Milestone ML 401 AUDIO VIDEO Manual

Operation :

There are two options to operate this unit
A. Manual Mode
B. Scan Mode
Note : Above mode ( B) is not available in ML401AV ( VIDEO Audio) Switcher.
A. Manual Mode Installation:
Selection of Manual mode:
To use the switcher in manual mode keep slide switch on manual mode on back panel of
the unit.
Local Keypad:
Select the required channel from the front panel keypad.
Remote contact closure / remote keypad
Rear panel has a D9 Male connecter, where you can connect Milestone RF/IR/ cable
through remote contact closure or you can connect programmable any other key pad or
remote which is available in market.
The connecter diagram for D9 male connector is as follows:
D-9 Male
1
2
:
:
8
9
Note : to select channel 1, short 1 and 9 through contact switch or use Milestone's
remote keypad / RF remote controller / IR remote controller.
3
Phone: 91-79-55310266 / 55124898 (M) 0-98253-50221
www.interfaceproducts.info
Channels
CH1
CH2
:
:
CH8
GRD
