Eclipse Buffet
Assembly Instructions
11x2
Attach panel [10] to panel [9].
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
9
12
10
9
Attach panel [11] to panels [9] and [10] and secure with 2x bolts (L).
Tighten with an Allen Key (P).
P
L
L
11
10
L
9
