Summary of Contents for Mocka Eclipse Console Table
- Page 1 Hello, I’ve arrived! Now that I’m here you are only one flat-pack away from transforming your home.
- Page 2 Thank you for supporting us. We believe design belongs to everyone. From materials and processes to safety testing, production and delivery, we are passionate and committed to bringing you the best possible product so you can create beautifully functional spaces to feel comfortably you. Here are a few assembly tips before you get started: Make Time Set The Mood...
- Page 3 The fixing device provided should fit most wall types, but please note that different wall materials may require different fixing devices from those supplied. Phillips & Flathead screwdrivers For quicker assembly, we recommend the use of a power drill on a low-speed setting. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 4 Insert 6x bolts (C) into panel [1] and tighten with a screwdriver. Attach 1x slide rail (F) and 1x slide rail (G) to panel [4] and [5] as shown and secure with 6x screws (E). Tighten with .a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 5 Slide panel [6] down along the grooves between the panels [3] secure with 6x locking nuts (D). Tighten with a screwdriver. and [5] to form the back of the unit as shown. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 6 Attach panels [7] and [8] to panels [9], [10] and [11] with 8x bolt (L). secure with 6x screws (B). Tighten with a screwdriver. Tighten with an Allen Key (P). mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 7 10 3 Insert 4x bolts (C) into panel [12]. Tighten with a screwdriver. Attach panels [7], [8], [9] and [10] to panel [2] with 10x screws (N). Tighten with a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 8 Attach panels [13], [14] and [15] as shown using 4x screws (N). Slide panel [16] down along the grooves between the side panels [13] and [15]. Tighten with a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 9 (D). Tighten with a screwdriver. Attach slide rail (I) and slide rail (H) to the underside of the side panels as shown. Secure with 4x screws (E) and tighten with a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 10 1x washer (Z) and 1x screw (W). Tighten with a screwdriver. Attach panel [17] to panels [7], [8] and [10] with 4x bolt (L). Tighten with an Allen Key (P). mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 11 (V). Fasten to the wall using 1x washer (Z), 1x wall anchor (X) and 1x screw (Y). Ensure unit is balanced and steady before use. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 12 Love it for longer. Remove all liquid and food spills immediately ONLY with a clean, damp, undyed white cloth. Do NOT use abrasives or common household detergents. Caring for our world. In the interest of our environment, please dispose of all packaging thoughtfully. Good news, you’re all done! Love it and share it on Instagram by tagging @mockaaustralia | @mockanz...
