- Page 1 Hello, I’ve arrived! Now that I’m here you are only one flat-pack away from transforming your home.
- Page 2 Thank you for supporting us. We believe design belongs to everyone. From materials and processes to safety testing, production and delivery, we are passionate and committed to bringing you the best possible product so you can create beautifully functional spaces to feel comfortably you. Here are a few assembly tips before you get started: Make Time Set The Mood...
- Page 3 The fixing device provided should fit most wall types, but please note that different wall materials may require different fixing devices from those supplied. Phillips & Flathead screwdrivers For quicker assembly, we recommend the use of a power drill on a low-speed setting. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 4 Insert 5x bolts (C) into panel [1] and tighten with a screwdriver. Attach 4x slide rails (F) and 4x slide rails (G) to panels [3] and [4] as shown and secure with 24x screws (E). Tighten with .a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 5 Insert 10x bolts (C) into panels [3] and [4]. Tighten with a screwdriver. Attach panels [5], [6], [7] and [8] to panel [3] with 2x dowels (A) and secure with 5x locking nuts (D). Tighten with a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 6 Attach panel [4] to panels [5], [6], [7] and [8] with 2x dowels (A) [8] to form the back of the unit as shown. and secure with 5x locking nuts (D). Tighten with a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 7 Attach panel [1] to panels [3], [4], [5] and [7] with 6x dowels (A) and and [4] to form the back of the unit as shown. secure with 5x locking nuts (D) and 3x screws (B). Tighten with a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 8 Attach panel [2] to the unit with 4x dowels (A) and secure with Attach panels [10] to panels [11] and panels [12] and secure with 4x screws (B). Tighten with a screwdriver. 8x bolt (L). Tighten with an Allen Key (P). mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 9 Drawers x4 Insert 20x bolts (C) into panels [13] and [14]. Tighten with a screwdriver. Attach panels [11] to panel [2] as shown using 6x screws (O). Tighten with a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 10 Attach panels [15], [16] and panel [17] to panels [13] and [14] and Slide panels [18] along the grooves between the side secure with 20x locking nuts (D). Tighten with a screwdriver. panels [15] and [16] as shown. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 11 Attach slide rail (I) and slide rail (H) to the underside of the side panels [15] Tighten with a screwdriver. and [16] as shown. Secure with 16x screws (E) and tighten with a screwdriver. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 12 2x washers (Z), 2x wall anchors (X) and 2x wall screws (Y). Ensure unit using 2x washers (Z) and 2x screws (W). Tighten with a screwdriver. is balanced and steady before use. You’re done, enjoy! mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 13 Fasten to the wall using 1x washers (Z), 1x wall anchor (X) and 1x wall Tighten with a screwdriver. screw (Y). Ensure unit is balanced and steady before use. You’re done, enjoy! mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 14 Four Drawer After installation, if the two handles are not aligned, loosen the screws in the back, adjust the two handles to align them, and then tighten the screws back up. mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008...
- Page 15 Love it for longer. Remove all liquid and food spills immediately ONLY with a clean, damp, undyed white cloth. Do NOT use abrasives or common household detergents. Caring for our world. In the interest of our environment, please dispose of all packaging thoughtfully. Good news, you’re all done! Love it and share it on Instagram by tagging @mockaaustralia | @mockanz...
