- Page 1 ASSEMBLY Tonic Acrylic Infill Screen 360.394.1300 watsonfurniture.com V.1.00 06/2020...
- Page 2 Tonic Acrylic Infill Screen Basic Components Acrylic Screen Bracket Acrylic Screen Infill Panel 2 TONIC ACRYLIC INFILL SCREEN ASSEMBLY INSTRUCTIONS...
- Page 3 Hardware BHSC S 5/16-18 x 3/4” M4-0.7 X 5mm Black (124755 ) F lat T ip Set Screw ( 0001612) Tools 3/16” Allen Wrench 2mm Allen Wrench...
- Page 4 Attach Brackets to Infill Panel Connect the Acrylic Screen Brackets to the Infill Panel with the provided screws (124755). Ensure that the brackets are in line with each other and parallel to the edge of the Infill. BHSC S 5/16-18 x 3/4” Black (124755 ) Attach Acrylic Screen to Brackets Slide the Acrylic Screen into the brackets.
- Page 5 Place Infill Assembly in Table Place the Infill assembly in the table and turn the security clips to lock the assembly in place. 5 TONIC ACRYLIC INFILL SCREEN ASSEMBLY INSTRUCTIONS...
