Technical Specifications; Art. Ut2020 - Comelit Simplebus2 Ultra UT2020 Technical Manual

Technical specifications

Art. UT2020

Product height (mm)
Product depth (mm)
COMPATIBLE SYSTEMS
Simplebus2 audio/video with power supply
unit Art. 1210/1210A
AUDIO SPECIFICATIONS
Technologies implemented
CAMERA FEATURES
Viewing angle (H x V - °)
Resolution (H x V - pixel)
ELECTRICAL SPECIFICATIONS
Type of power supply
Power supply voltage
Absorption in standby (W)
Maximum absorption (W)
HARDWARE CHARACTERISTICS
Number of buttons (no.)
Number of inputs (no.)
Number of outputs (no.)
Communication port
Loudspeaker volume
Backlighting brightness
PROGRAMMING MODE
Manual (by means of Dip Switches)
ViP Manager software
ENVIRONMENTAL AND CONFORMITY
IP protection rating (when installed)
IK anti-vandal protection rating
Operating temperature (°C)
Operating humidity (max RH - %)
Environmental class
Conformity and Certifications
MAIN FUNCTIONS
Number of auxiliary relays (no.)
Input for local key button
Input for door open signal
System status visual indications
System status audio indications
System status voice synthesis
6
GENERAL DATA
Type Modular
90
Product width (mm) 100
35
Product colour Black RAL9005, Transparent, Aluminium
Product weight (g) 350
Material Polycarbonate, Aluminium alloy
Flush mounting Yes, with specific accessory
Surface mounting Yes, with specific accessory
Yes
Microphone MEMS digital audio sensor, omnidirectional
Loudspeaker 28 mm (Ø), 8 Ohm, 1W (2)
Full-Duplex
Camera Colour
Sensor type 1/3" CMOS
Lens (mm) 1.79
120 x 90
Sensitivity (lux) 0.45
1288 x 968
Power supply via video entry bus
33 VDC
1.5
6
Call type Buttons
Type of buttons Mechanical
2
Backlighting colour White, Off
Terminals L L V+ V- COM NC NO SE+ SE-/GND RTE TX- TX+ RX- RX+
1
2
Output type Relay (C-NO-NC, 4A@12-24 VAC/VDC, inrush current 10A)
Micro-USB
Twilight sensor Yes
SETTINGS
Yes
Mic volume Yes
Yes
Yes
Yes
SPECIFICATIONS
IP65
IK08
-25 to 55
25 to 95
IV
RoHS II - 2011/65/EU (EN 50581:2012), EMC 2014/30/EU (EN 61000-6-
1:2007, EN 61000-6-3:2007+A1:2011)
Lock-release Yes
1
Yes
Yes
Yes
Yes
Yes
