Digital call module Art. 3360B/3360BM
EN
TECHNICAL
MANUAL
1
2
3
ABC
DEF
GHI
4
5
6
JKL
MNO
PQRS
7
8
9
TUV
WXYZ
.;:
X
0
A
B
C
E
F
D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3360B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comelit 3360B

Summary of Contents for Comelit 3360B

  • Page 1 TECHNICAL MANUAL PQRS WXYZ Digital call module Art. 3360B/3360BM...

  • Page 2: Table Of Contents

    6A. Enabling/disabling self-ignition 7. Default settings 7A. Restoring the default values of the porter module Software Art. 1249B 1. Installing the USB driver for connecting Art. 3360B to a PC 2. Using the directory via software Art. 1249B 3. Multidownload Menu diagram...

  • Page 3: General Description

    General description The Comelit digital call module Art. 3360B can be used in Simplebus, Simplebus Top Building Kit and Vip systems, and is fitted with a name directory to store a list of names and passwords as well as an alphanumerical keypad to call users by entering their identification code.

  • Page 4: Self-Testing

    Self-testing SELECT LANGUAGE ITALIANO On power-up, the device carries out a diagnostic test of *ENGLISH the connections to check the correct communication and FRANCAIS configuration of the porter module (Art. 1622, 1622VC, 1621, 1621VC, 1682, 1682HVC, 4680C, 4681, 4682HC). The message PLEASE WAIT indicates self-testing in pro- gress.

  • Page 5: Finding A Name In The Directory

    1B. or scroll through the directory using ` to exit, press 3. Activating the door opening relay by MARIO ROSSI entering the password code ` standby mode 1. press CODE: ENTER PASSWORD: SCROLL CALL 2. to call, press 3. to exit, press CANC 2.

  • Page 6: Accessing The Programming Mode

    Accessing the programming mode 3. press to confirm 4. enter the name using the alphanumeric keypad, for the 1A. connect terminal PRG to GND and power up the use of special characters see table on page 3 module 1B. or press and enter the default supercode 778899 MARIO ROSS_ ENTER PASSWORD:...

  • Page 7: Deleting A Name In The Directory

    ENTER NAMES MARIO ROSSI_ DELETE NAMES CHANGE NAMES CLEAR ALL NAMES SCROLL CANC SCROLL CANC 8. change the name using the alphanumeric keypad, for 3. press to confirm the use of special characters see table on page 3 9. press to confirm 10.

  • Page 8: Clearing The Directory

    4. Clearing the directory 3. press to confirm 1. access programming mode, see page 6 2. select the menu items: Name directory ⇒ Clear all names ENTER PART OF THE NAME ENTER NAMES REQUIRED DELETE NAMES CHANGE NAMES CLEAR ALL NAMES 4.

  • Page 9: Access Control

    2. Restoring the default supercode (778899) Access control 1. Changing the default supercode (778899) 1. access programming mode, see page 6 2. select the menu items: The supercode (778899 is the default code) is used to Access control ⇒ Supercode ⇒ Default settings access the programming menus.

  • Page 10: Deleting A Password Code

    3. press to confirm DELETE PASSWORD: 4. enter the password (max. 6 characters consisting of numbers and/or letters from A to F) using the alphanumeric _ 3ABC4 keypad IMPORTANT: the password must be at least 4 characters long CANC ENTER PASSWORD: 5.

  • Page 11: Erasing All Passwords

    DELETION COMPLETE 3ABC4 5. to exit, press SCROLL Settings of the directory module (Art. 3360B) 6. Erasing all passwords 1. Modifying the language setting 1. access programming mode, see page 6 2. select the menu items: 1. access programming mode, see page 6 Access control ⇒...

  • Page 12: Setting The Type Of Remote Connection

    SELECT LANGUAGE TYPE OF DOWNLOAD ITALIANO *ENGLISH *USB FRANCAIS RS485 SCROLL SCROLL » * indicates language selected » * indicates the type of download selected 6. to exit, press 6. to exit, press 2. Setting the type of remote connection 3.

  • Page 13: Disabling The Second Language

    Art. 1424 in Top 1, 2, 3 mode (see FT SB 21, page 6) 4. Disabling the second language which define the system zones. Module Art. 3360B in Simplebus Top mode must be used in conjunction with compatible products (see table To cancel the second language function: “Simplebus Top products”, page 34).
  • Page 14 Art. SCROLL CALL 3360B. Since a single user code (apartment) can have up to 2 access keys associated with it under different names, during a numerical code call from the digital module the first 2.

  • Page 15: Enabling/Disabling Name-Only Display

    CAUTION: to modify the type of system and the call mode CALL MANAGEMENT it is necessary to erase the entire directory, see page 8. *STANDARD 1. set the selector on porter module Art. 1622, 1622VC, INDIRECT CODE 1621, 1621VC, 4680C, 4681 to ON, see Fig. IMMOTEC STANDARD 2.

  • Page 16: Enabling/Disabling The Welcome Message

    8. Entering the welcome message NAME ONLY This function is disabled by default. It is possible to enter the welcome message using software Art. 1249B. 1. access programming mode, see page 6 2. select the menu items: SCROLL ` Settings ⇒ Welcome message ⇒ Change 4.

  • Page 17: Enabling/Disabling The Welcome Message

    9. Enabling/disabling the static message 3. press to confirm This function is disabled by default. SCREEN SAVER If activated, the welcome message will appear and remain on the display after a 30-second period of inactivity. 1. access programming mode, see page 6 2.

  • Page 18: Changing Keypad Speed

    12. Changing keypad speed KEYPAD TONE *YES The "keypad speed" parameter determines the speed with which prolonged pressing of a key is converted into "multiple presses of the same key". The default keypad speed setting is high. 1. access programming mode, see page 6 2.

  • Page 19: Changing The Rs485 Address Of The Porter Module

    16. Viewing the number of names entered in 4. select YES to enable the function, NO to disable it the directory, the software version, the number 5. press to confirm of passwords entered and the ID code (RS485 » * indicates active selection address) 1.

  • Page 20: Setting The Porter Module Parameters (Audio Time, Door Lock Time, Reset Time)

    Standard settings of the porter module (Art. 7. press to confirm 1622, 1621, 4680C, 4681) » confirmation tone 1. Setting the porter module parameters (audio time, door lock time, reset time) PARAMETER AUDIO TIME= 10 - 180 sec. CHANGED DOOR LOCK TIME= 1 - 8 sec. RESET TIME= 1 - 10 sec.

  • Page 21: Lock On Se

    Enabling/disabling door lock Advanced settings of the porter module (Art. confirmation tone on the porter module 1622, 1621, 4680C, 4681) This function is disabled by default. 1. Lock on SE 1. access programming mode, see page 6 2. select the menu items: 1A.

  • Page 22: Enabling/Disabling The Standby Lock Release On The Porter Module

    1C. Enabling/disabling the standby lock release 1D. Viewing the parameters of the door lock on on the porter module the SE output of the porter module This function is enabled by default. 1. access programming mode, see page 6 1. access programming mode, see page 6 2.

  • Page 23: Enabling/Disabling The Relay Contact In Parallel To The Porter Module Se Output

    ACTUATOR FUNCTION PARAMETER CHANGED SCROLL 2B. Enabling/disabling the relay contact in 4. select YES to enable the function, NO to disable it parallel to the porter module SE output 5. press to confirm » * indicates active selection » confirmation tone 1.

  • Page 24: Viewing The Relay Contact Parameters

    2C. Viewing the relay contact parameters 3. S serial 3A. Enabling/disabling the actuator function on 1. access programming mode, see page 6 the S serial line 2. select the menu items: Settings ⇒ System parameters ⇒ Speaker parameters 1. access programming mode, see page 6 ⇒...

  • Page 25: Voice Messages

    It is possible to enable or disable the triple call made by Art. Settings ⇒ System parameters ⇒ Speaker parameters 3360B to the internal units. ⇒ Advanced options ⇒ Voice messages The call will therefore take place on consecutive occasions...

  • Page 26: Enabling/Disabling The Call Confirmation Tone

    5B. Enabling/disabling the call confirmation 5C. Enabling/disabling the call codes booster tone This function is enabled by default. This function is disabled by default. 1. access programming mode, see page 6 Allows control of over 70 internal units connected to porter 2.

  • Page 27: Setting The Call Answer Wait Time

    5D. Setting the call answer wait time 5E. Viewing the porter module call parameters 1. access programming mode, see page 6 1. access programming mode, see page 6 2. select the menu items: 2. select the menu items: Settings ⇒ System parameters ⇒ Speaker parameters Settings ⇒...

  • Page 28: Default Settings

    Control of internal units connected to porter module = up 1. Installing the USB driver for connecting Art. to 70 3360B to a PC System mode = Simplebus CAUTION: make sure that the option to install unsigned drivers (drivers that have not passed Windows Logo 7A.

  • Page 29: Using The Directory Via Software Art. 1249B

    3. Multidownload TYPE OF DOWNLOAD It is possible to use a RS485 network to connect multiple *USB Art. 3360B to the same PC with software Art. 1249B RS485 installed. Each module must have a different ID CODE (RS485 address), see page 18.

  • Page 30: Menu Diagram

    Menu diagram NAME ENTER functions available in Simplebus, Simplebus TOP and ViP mode DIRECTORY NAMES functions not available in ViP mode DELETE NAMES CHANGE NAMES CLEAR ALL DELETE NAMES ALL NAMES? ACCESS ENTER NEW SUPERCODE CONTROL CODE DEFAULT SETTINGS PASSWORD ENTER DELETE SEARCH...
  • Page 31 SYSTEM ADVANCED LOCK SETTINGS PARAMETERS OPTIONS ON SE CONFIRMATION TONE STANDBY LOCK REL. VIEW RELAY ACTUATOR ACTIVATION CONTACT FUNCTION TIME IN PARALLEL TO SE VIEW ACTUATOR S SERIAL FUNCTION VOICE MESSAGES ITALIANO FRANCAIS ESPANOL NEDERLANDS GREEK ENGLISH CALL TRIPLE CALL 31 31...
  • Page 32 SPEAKER ADVANCED CALL SETTINGS SETTINGS PARAMETERS OPTIONS CONFIRMATION TONE CODES BOOSTER ANSWER WAIT TIME VIEW SELF IGNITION DEFAULT SETTINGS RS485 ADDRESS SELECT ITALIANO LANGUAGE ENGLISH FRANCAIS DEUTSCH PORTUGUES DEFAULT SECOND ITALIANO LANGUAGE ENGLISH FRANCAIS 32 32...
  • Page 33 SECOND SETTINGS LANGUAGE DEUTSCH PORTUGUES DEFAULT CALL SIMPLEBUS STANDARD MANAGEMENT INDIRECT CODE IMMOTEC STAND. IMMOTEC INDIRECT SIMPLEBUS STANDARD INDIRECT CODE IMMOTEC STAND. IMMOTEC INDIRECT STANDARD IMMOTEC STAND. NAME ONLY WELCOME CHANGE MESSAGE ENABLE STATIC MESSAGE 33 33...

  • Page 34: Table Of Simplebus Top Products

    SETTINGS SCREEN SAVER KEYPAD SENS. MEDIUM HIGH KEYPAD SPEED MEDIUM HIGH KEYPAD TONE DEFAULT SETTINGS INFO FW REVISION NAMES STORED PASSWORDS ENTERED RS485 ADDRESS Table of Simplebus Top products Door-entry phones Art. 2608 IR. 006 / Art. 2610 IR. 008 / Art. 2619 IR. 000 Art.

  • Page 35: Diagram

    3360B 120E 1/4W 4681 3360B 4681 3360B CAUTION: - It is possible to use up to 5 terminals Art. 3360B - Maximum distance between Art. 20022618 and furthest terminal Art. 3360B: 100 m Computer ALIM. MOXA TCC-80 20022618 1595...
  • Page 36 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
