- Page 1 TECHNICAL MANUAL Audio/video module for Simplebus2 Ultra Art. UT2020 Simplebus2 Ultra remote camera audio module Passion.Technology.Design. Art. UT2010VC...
-
Page 2: Warning
• any purpose other than the intended use, • failure to observe the indications and warnings contained in this Manual / Instruction sheet. Comelit Group S.p.A. reserves the right to change the information provided in this Manual / Instruction Sheet at any time and without prior notice. -
Page 3: Table Of Contents
Table of contents Warning .................... 2 Description ..................4 UT2020 ......................4 UT2010VC ....................4 Installation notes (Art. UT2020) ............6 Technical characteristics ..............7 Art. UT2020 ....................7 Art. UT2010VC ..................8 Installation ..................9 Flush-mounted installation composition table ........9 Surface-mounted installation composition table ........9 Flush-mounted installation ............ -
Page 4: Description
Description UT2020 Audio/video module for Ultra entrance panel, Simplebus2 system. For use in systems with power supply unit art. 1210 / 1210A. Wide-angle colour video camera (field of vision: 120° horizontal, 90° vertical) UT2010VC Audio module designed for connection of an analogue remote camera with PAL standard for Ultra entrance panel, Simplebus2 system. - Page 5 4. 5. 6. 15. 16. Art. UT2010VC 1. Indicator LEDs 14. Terminal block for connection: call sent (green) / system busy (red) RTE programmable RTE (local lock-release input) or DO input (door open indication) lock-release enabled GND SE- RTE and door lock input reference negative audio enabled SE+ electric door lock connection...
-
Page 6: Installation Notes (Art. Ut2020)
Installation notes (Art. UT2020) 90° 175 cm 120° The camera must not be installed in front of light sources, or in places where the filmed subject is against the light. In dim environments, we recommend additional lighting is provided. -
Page 7: Technical Characteristics
Technical characteristics Art. UT2020 GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product colour Black RAL9005, Transparent, Aluminium Material Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting Yes, with specific accessory COMPATIBLE SYSTEMS Simplebus2 audio/video with power supply unit Art. -
Page 8: Art. Ut2010Vc
Art. UT2010VC GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product colour Black RAL9005, Transparent, Aluminium Material Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting Yes, with specific accessory COMPATIBLE SYSTEMS Simplebus2 audio/video with power supply unit Art. -
Page 9: Installation
Installation The entrance panel is available in flush-mounted or surface-mounted variants: Flush-mounted installation composition table 3110/1 3110/2 3110/3 3110/4 UT9181 UT9182 UT9183 UT9186 UT9189 UT9184 UT9188 A = Flush-mounted box B = Rain shield C = Flush-mounted module holder UT9161 UT9162 UT9163 UT9164... -
Page 10: Flush-Mounted Installation
Flush-mounted installation Optional Optional BLACK... -
Page 11: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). MAX 0,2 mm The total thickness of the nameplate + adhesive label must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download MAX 0,2 mm the PDF to print the entrance panel name cards, using the... -
Page 12: Installation With Side-By-Side Boxes
Installation with side-by-side boxes Before installing the boxes in the wall, fit the spacers. -
Page 13: Wall-Mounted Installation
Wall-mounted installation Optional Optional BLACK... -
Page 14: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). MAX 0,2 mm The total thickness of the nameplate + adhesive label must not exceed 0.2 mm. MAX 0,2 mm You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the... -
Page 15: Installation With Side-By-Side Boxes
Installation with side-by-side boxes... -
Page 16: Connections
Connections Connections for Art. UT2020, UT2010VC 1210A 1210 R GND NO NC UT2020 UT2010VC Max 20 m. Local door-opener button. UT2020, UT2010VC connections with separate power supply 1210A 1595 1210 120-230 V R GND NO NC UT2020 UT2010VC Max 20 m. Local door-opener button. Variants Variant for using the outdoor entrance panel relay Variant for using a safety door lock... -
Page 17: Remote Camera Connection (Art. Ut2010Vc Only)
Remote camera connection (Art. UT2010VC only) 1210A 1210 R GND NO NC UT2010VC BLACK BLACK Max 20 m. Local door-opener button. -
Page 18: Module Connection
Module connection On systems with Art. UT2020/UT2010VC and power supply unit Art. 1210/1210A, the maximum current available for the outdoor entrance panel modules is 100 mA. Calculate the total power consumption of the modules in your system configuration using the Consumption table. -
Page 19: Connection Of Button Modules Art. Ut9200
Connection of button modules Art. UT9200 1210A 1210 R GND NO NC BLACK UT2020 UT2010VC UT9200 MAX 8 Max 20 m. Local door-opener button. Max 8 modules (Max 30 modules with additional power supply). Connection of Touch-screen module Art. UT9270 Variant with separate power supply up to 80 users >... -
Page 20: Programming
Programming For correct programming, follow the instructions below in order Configure button type Address button modules III. Program call addresses Configure button type (single/dual) DIP 6: configuring button type: Single button (DIP6 ON). default Dual button (DIP6 OFF, default). DIP 6: configuring button type: Single button (DIP6 ON). -
Page 21: Smart Programming Of Consecutive Addresses
Smart programming of consecutive addresses Make sure the button configuration (single/dual) is correct before proceeding with programming (see “Configure button type (single/dual)”) S1 S2 Take note of the DIP-switch settings Set the address of the apartment you wish 1 2 3 4 to call (for example: 1) example: using the DIP-... -
Page 22: Programming Of Specific Addresses
Programming of specific addresses Make sure the button configuration (single/dual) is correct before proceeding with programming (see “Configure button type (single/dual)”) S1 S2 Take note of the DIP-switch settings Set the address of the apartment you wish to 1 2 3 4 call (for example: 25) example: using the DIP-... -
Page 23: Special Programming Via Dip-Switch
Special programming via DIP-switch S1 S2 Take note of the DIP-switch settings 1. Set the dip switches in accordance with the function you wish to program (see table). 2. Press the confirm button. S1 S2 When programming is complete, make sure the button configuration is correct (single/dual), see Reset the configuration of the... -
Page 24: Special Programming Table
Special programming table CODE DIP SWITCHES ON FUNCTIONS Audio-visual messages 1,2,7,8 Hebrew 3,7,8 Polish 1,3,7,8 Catalan 2,3,7,8 Galician 1,2,3,7,8 Basque 2,3,4,7,8 Danish 1,2,3,4,7.8 Norwegian 1,2,5,7,8 Swedish 1,2,3,5,7.8 Italian 4,5,7,8 French 1,4,5,7,8 Spanish 2,4,5,7,8 Dutch 1,2,4,5,7.8 Greek 3,4,5,7,8 English 1,3,4,5,7.8 German 2,3,4,5,7.8 Portuguese 2,4,7,8... - Page 25 1,2,5,6,7.8 Reset wait time (after hang-up or after lock-release): 10 sec (default) 3,5,6,7,8 Reset wait time (after hang-up or after lock-release): 1 sec 5,7,8 Enables “Reset wait time" on lock-release command (default) Disables “awaiting reset time" on lock-release command (awaiting response time or talk time will be 1,5,7,8 activated) 1,4,5,6,7.8...
-
Page 26: Twilight Sensor
Twilight sensor Camera LED lighting and button backlighting management The twilight sensor is in AUTO mode by default: the camera and button LEDs light up at night and switch off during the day. To change the setting to ON (LEDs always on) or OFF (LEDs always off), proceed as follows: S1 S2 Take note of the DIP-switch... -
Page 27: Checking Twilight Sensor Operation
Checking twilight sensor operation S1 S2 S1 S2 5 sec If it is daytime and you want to check AUTO mode operation for the twilight sensor, you can proceed as follows: 1. Enter programming mode 2. Block the twilight sensor for 5 seconds »... -
Page 28: Adjusting The Brightness Of The Button Leds And The Camera Light
Adjusting the brightness of the button LEDs and the camera light S1 S2 Take note of the DIP-switch settings Enable brightness control (A) for the camera (code 171) cod. 171 (B) for the buttons (code 161) 1 2 3 4 Set the desired function (code 171/161) and press the confirm cod. -
Page 29: Light-Me Function
S1 S2 When programming is complete, make sure the button configuration is correct (single/dual), see Reset the configuration of the “Configure button type DIP-switches (single/dual)”) Light-me function Thanks to this function, button backlighting is only enabled on the user’s request, by pressing the LIGHT-ME button on the audio/video module;... -
Page 30: Replacing The Audio/Video Module With Programming Restore Backup
Replacing the audio/video module with programming restore backup If the audio or audio/video module is replaced, the following instructions must be observed. The procedure should be completed within one hour of removal of the old module. Take note of the DIP-switch settings 1. -
Page 31: Configuring Via Pc
Configuring via PC All device configurations can be performed via PC and ViP Manager configuration software, available to download free of charge from pro.comelitgroup.com. √ You will need a USB micro-USB cable. Errors and indications INDICATION SOLUTION Line short-circuit Check connections Remove jumper J4 on the audio/video Dual power supply present module... -
Page 32: Addressing Table
Addressing table Dip switch Code 1,2,3,4,5 1,3,4,5,6 1,2,4,5,7 1,4,5,6,7 1,2,3,5,8 1,3,5,6,8 1,2,5,7,8 2,3,4,5,6 3,4,5,7 2,4,5,6,7 4,5,8 2,3,5,6,8 3,5,7,8 1,2,3,4,5.6 1,3,4,5,7 1,2,4,5,6.7 1,4,5,8 1,2,3,5,6.8 1,3,5,7,8 2,3,4,5,7 3,4,5,6,7 2,4,5,8 4,5,6,8 2,3,5,7,8 1,2,6 1,2,3,4,5.7 1,3,4,5,6.7 1,2,4,5,8 1,4,5,6,8 1,2,3,5,7.8 2,3,4,5,6.7 3,4,5,8 2,4,5,6,8 4,5,7,8 1,2,3 1,3,6 1,2,7 1,6,7... - Page 33 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
