- Page 1 TECHNICAL MANUAL Audio/video module for Simplebus2 Ultra Art. UT2020 Simplebus2 Ultra remote camera audio module Passion.Technology.Design. Art. UT2010VC...
-
Page 2: Table Of Contents
• We advise against running the system wires through the same duct as the power cables (230V or higher). • To ensure Comelit products are used safely: carefully observe the indications provided in the manuals / instruction sheets and make sure the system created using Comelit products has not been tampered with / damaged. -
Page 3: Description
Description UT2020 Audio/video module for Ultra entrance panel, Simplebus2 system. For use in systems with power supply unit art. 1210 / 1210A. Wide-angle colour video camera (field of vision: 120° horizontal, 90° vertical) UT2010VC Audio module designed for connection of an analogue remote camera with PAL standard for Ultra entrance panel, Simplebus2 system. - Page 4 4. 5. 6. 15. 16. Art. UT2010VC 1. Indicator LEDs 14. Terminal block for connection: call sent (green) / system busy (red) RTE programmable RTE (local lock-release input) or DO input (door open indication) lock-release enabled GND SE- RTE and door lock input reference negative communication enabled SE+ electric door lock connection...
-
Page 5: Installation Notes (Art. Ut2020)
Installation notes (Art. UT2020) 90° 90° 90° 50 cm 50 cm 50 cm 175 cm 120° The camera must not be installed in front of light sources, or in places where the filmed subject is against the light. In dim environments, we recommend additional lighting is provided. -
Page 6: Technical Specifications
Technical specifications Art. UT2020 GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product colour Black RAL9005, Transparent, Aluminium Product weight (g) Material Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting Yes, with specific accessory COMPATIBLE SYSTEMS Simplebus2 audio/video with power supply unit Art. -
Page 7: Art. Ut2010Vc
Art. UT2010VC GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product colour Black RAL9005, Transparent, Aluminium Product weight (g) Material Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting Yes, with specific accessory COMPATIBLE SYSTEMS Simplebus2 audio/video with power supply unit Art. -
Page 8: Installation
Installation The entrance panel is available in flush-mounted or surface-mounted variants: Flush-mounted installation composition table A = Flush-mounted box B = Rain shield C = Flush-mounted module holder with finishing frame 3110/1 3110/2 3110/3 3110/4 3110/1A 3110/2A 3110/3A 3110/4A UT9181 UT9182 UT9184H UT9183... -
Page 9: Flush-Mounted Installation
Flush-mounted installation Optional Optional BLACK... -
Page 10: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). MAX 0,2 mm The total thickness of the nameplate + adhesive label must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the MAX 0,2 mm... -
Page 11: Installation With Side-By-Side Boxes
Installation with side-by-side boxes Before installing the boxes in the wall, fit the spacers. -
Page 12: Wall-Mounted Installation
Wall-mounted installation Optional Optional BLACK... -
Page 13: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). The total thickness of the nameplate + adhesive label MAX 0,2 mm must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the MAX 0,2 mm... -
Page 14: Installation With Side-By-Side Boxes
Installation with side-by-side boxes... -
Page 15: Connections
Connections Connections for Art. UT2020, UT2010VC 1210A 1210 R GND NO NC UT2020 UT2010VC Max 20 m. Local door-opener button. UT2020, UT2010VC connections with separate power supply 1210A 1595 1210 120-230 V R GND NO NC UT2020 UT2010VC Max 20 m. Local door-opener button. Variants Variant for using the outdoor entrance panel relay Variant for using a safety door lock... -
Page 16: Remote Camera Connection (Art. Ut2010Vc Only)
Remote camera connection (Art. UT2010VC only) 1210A 1210 R GND NO NC UT2010VC BLACK BLACK Max 20 m. Local door-opener button. -
Page 17: Module Connection
Module connection On systems with Art. UT2020/UT2010VC and power supply unit Art. 1210/1210A, the maximum current available for the outdoor entrance panel modules is 100 mA. Calculate the total power consumption of the modules in your system configuration using the Consumption table. -
Page 18: Connection Of Button Modules Art. Ut9200
Connection of button modules Art. UT9200 1210A 1210 R GND NO NC BLACK UT2020 UT2010VC UT9200 MAX 8 Max 20 m. Local door-opener button. Max 8 modules (Max 30 modules with additional power supply). Connection of Touchscreen module Art. UT9270 Variant with separate power supply Maximum 80 users... -
Page 19: Programming
Programming For correct programming, follow the instructions below in order Configure button type Address button modules III. Program call addresses Configuring the button type to maintain during normal operation (single/dual) DIP 6: configuring button type: Single button (DIP6 ON). default Dual button (DIP6 OFF, default). -
Page 20: Smart Programming Of Consecutive Addresses
Smart programming of consecutive addresses default DIP 6: configuring button type: Single button (DIP6 ON). Dual button (DIP6 OFF, default). Set the address of the apartment you wish to call (for example: 1) using the DIP-switches 1 2 3 4 (see “Addressing table”... -
Page 21: Programming Of Specific Addresses
Programming of specific addresses default DIP 6: configuring button type: Single button (DIP6 ON). Dual button (DIP6 OFF, default). Set the address of the apartment you wish to call (for example: 25) using the DIP-switches 1 2 3 4 (see “Addressing table” S1 S2 1 2 3 4 example:... -
Page 22: Special Programming Via Dip Switch
Special programming via DIP Switch S1 S2 Take note of the DIP-switch settings 1. Set the dip switches in accordance with 1 2 3 4 the function you wish to program (see “Special programming table”). 2. Press the confirm button. S1 S2 Reset the configuration of the DIP-switches... -
Page 23: Special Programming Table
Special programming table CODE DIP SWITCHES ON FUNCTIONS Audio-visual messages 1,2,7,8 Hebrew 3,7,8 Polish 1,3,7,8 Catalan 2,3,7,8 Galician 1,2,3,7,8 Basque 2,3,4,7,8 Danish 1,2,3,4,7.8 Norwegian 1,2,5,7,8 Swedish 1,2,3,5,7.8 Italian 4,5,7,8 French 1,4,5,7,8 Spanish 2,4,5,7,8 Dutch 1,2,4,5,7.8 Greek 3,4,5,7,8 English 1,3,4,5,7.8 German 2,3,4,5,7.8 Portuguese 2,4,7,8... - Page 24 1,2,4,5,8 System busy signalling time: 300 sec 1,2,3,4,6,7,8 Confirmation tone on user call = enabled (default) 5,6,7,8 Confirmation tone on user call = disabled 1,2,5,6,7.8 Reset wait time (after hang-up or after lock-release): 10 sec (default) 3,5,6,7,8 Reset wait time (after hang-up or after lock-release): 1 sec 5,7,8 Enables “Reset wait time"...
-
Page 25: Twilight Sensor
Twilight sensor Camera LED lighting and button backlighting management The twilight sensor is in AUTO mode by default: the camera and button LEDs light up at night and switch off during the day. To change the setting to ON (LEDs always on) or Take note of the DIP-switch OFF (LEDs always off), settings... -
Page 26: Checking Twilight Sensor Operation
S1 S2 Reset the configuration of the DIP-switches Checking twilight sensor operation S1 S2 S1 S2 5 sec If it is daytime and you want to check AUTO mode operation for the twilight sensor, you can proceed as follows: 1. Enter programming mode 2. -
Page 27: Adjusting The Brightness Of The Button Leds And The Camera Light
Adjusting the brightness of the button LEDs and the camera light S1 S2 Take note of the DIP-switch settings 1. Enable brightness control (A) for the camera light (code 171) or (B) for the buttons (code 161) 1 2 3 4 cod. -
Page 28: Light-Me Function
S1 S2 Reset the configuration of the DIP-switches Light-me function Thanks to this function, button backlighting is only enabled on the user’s request, by pressing the LIGHT-ME button on the audio/video module; this saves energy and reduces light pollution. Backlighting management for this button depends on the twilight sensor setting. It is in AUTO mode by default: the LEDs light up at night and switch off during the day. -
Page 29: Replacing The Audio/Video Module With Programming Restore Backup
Replacing the audio/video module with programming restore backup If the audio or audio/video module is replaced, the following instructions must be observed. The procedure should be completed within one hour of removal of the old module. Take note of the DIP-switch settings Wait 90 seconds Enter programming mode by moving S2 DIP-switch upwards... -
Page 30: Configuring Via Pc
Configuring via PC All device configurations can be performed via PC and ViP Manager configuration software, available to download free of charge from pro.comelitgroup.com (See programming manual) For example: • programming call addresses for the buttons • activating audiovisual indications •... -
Page 31: Addressing Table
Addressing table Cod. DIP-switch 1,4,6 1,5,7 1,4,5,6,7 1,6,8 1,4,7,8 2,4,6 2,5,7 2,4,5,6,7 2,6,8 2,4,7,8 1,2,4,6 1,2,5,7 1,2,4,5,6,7 1,2,6,8 1,2,4,7,8 3,4,6 3,5,7 3,4,5,6,7 3,6,8 3,4,7,8 1,3,4,6 1,3,5,7 1,3,4,5,6,7 1,3,6,8 1,3,4,7,8 2,3,4,6 2,3,5,7 2,3,4,5,6,7 2,3,6,8 2,3,4,7,8 1,2,3 1,2,3,4,6 1,2,3,5,7 127 1,2,3,4,5,6,7 1,2,3,6,8 1,2,3,4,7,8 4,5,7 4,6,8... - Page 32 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
