  • Page 1 Installation, Operation and Maintenance Instructions...
  • Page 3: Table Of Contents

    Table of Contents Table of Contents 1 Important Safety Notice ............................ 2 2 Safety warnings ..............................3 3 Safety.................................. 4 4 General precautions............................5 5 ATEX Considerations and Intended Use ......................9 6 Parts ................................. 11 7 General ................................12 7.1 Introduction..............................
  • Page 4: Important Safety Notice

    ITT Goulds pumps will provide safe, trouble-free service when properly installed, maintained, and operat- Safe installation, operation, and maintenance of ITT Goulds Pumps equipment are an essential end user responsibility. This Pump Safety Manual identifies specific safety risks that must be considered at all times during product life.
  • Page 5: Safety Warnings

    Trapped liquid can rapidly expand and result in a violent explosion and injury. ITT Goulds Pumps will not accept responsibility for physical injury, damage, or delays caused by a failure to observe the instructions for installation, operation, and maintenance contained in this Pump Safety Manual or the current IOM available at http://www.gouldspumps.com/literature.
  • Page 6: Safety

    Personal injury and/or equipment damage may occur if these instructions are not followed. If there is any question regarding these requirements or if the equipment is to be modified, please contact an ITT Goulds Pumps representative before proceeding. Example: Improper impeller adjustment could cause contact between the rotating and station- ary parts, resulting in a spark and heat generation.
  • Page 7: General Precautions

    Personal injuries will result if procedures outlined in this manual are not followed. ITT Goulds Pumps will not accept responsibility for physical injury, damage or delays caused by a failure to observe the instructions in this manual and the IOM provided with your equip- ment.
  • Page 8 Lift equipment only at specifically identified lifting points or as instructed in the current IOM. Current manuals are available at www.gould- spumps.com/literature_ioms.html or from your local ITT Goulds Pumps sales representative. Note: Lifting devices (eyebolts, slings, spreaders, etc.) must be rated, selected, and used for the entire load being lifted.
  • Page 9 4 General precautions WARNING Make sure to properly lubricate the bearings. Failure to do so may result in ex- cess heat generation, sparks, and / or premature failure. CAUTION The mechanical seal used in an ATEX classified environment must be proper- ly certified.
  • Page 10 4 General precautions WARNING Noise: Sound pressure levels may exceed 80 dbA in operating process plants. Clear visual warnings or other indicators should be available to those entering an area with unsafe noise levels. Personnel should wear appropriate hearing pro- tection when working on or around any equipment, including pumps.
  • Page 11: Atex Considerations And Intended Use

    Maintenance manual (IOM) can cause serious personal injury or damage to the equipment. This in- cludes any modification to the equipment or use of parts not provided by ITT Goulds Pumps. If there is any question regarding the intended use of the equipment, please contact an ITT Goulds representative before proceeding.
  • Page 12 The code classification marked on the equipment must be in accordance with the specified area where the equipment will be installed. If it is not, do not operate the equipment and contact your ITT Goulds Pumps sales representative before proceeding.
  • Page 13: Parts

    6 Parts The use of genuine Goulds parts will provide the safest and most reliable operation of your pump. ITT Goulds Pumps ISO certifica- tion and quality control procedures ensure the parts are manufac- tured to the highest quality and safety levels.
  • Page 14: General

    7 General 7 General 7.1 Introduction This instruction manual is intended to assist those involved with the installation, operation and mainte- nance of Goulds SPD slurry pumps. It is recommended that this manual be thoroughly reviewed prior to installing or performing any work on the pump or motor. 7.2 Importance of instructions The design, material and workmanship incorporated in the construction of Goulds SPD slurry pumps makes them capable of giving long, trouble-free service.
  • Page 15: Pump Installation

    7.8 Pump installation run of 15 minutes after the motor is no longer completely submerged if the sump is large enough to not have completed the pump-down in that time. The motor is rated for full horsepower with liquid temperatures of 40° C (104° F) or lower. 7.8 Pump installation Make sure the lifting device is securely fastened to the motor lugs or hooks so the unit will not be drop- ped when it is lowered into the sump.
  • Page 16 7.11 Excessive current draw Table 3: Typical parts list Item Number Qty per pump Part Name Casing Impeller Gasket Motor adapter or mount Gasket Hex nut 357A Hex nut 370C Hex capscrew, impeller 370R Hex capscrew 371W Hex capscrew 528J Washer 528L Washer...
  • Page 17 7.11 Excessive current draw Figure 2: Model HSU sectional assembly HSU Installation, Operation and Maintenance Instructions...
  • Page 18: Disassembly And Assembly

    7.12 Disassembly and assembly 7.12 Disassembly and assembly In the sectional assembly in this instruction, it should be noted that the motor adapter configuration var- ies with the motor frame. The various fastening arrangements are shown. Refer to the bill of material and sectional assembly certified for your order.
  • Page 19 7.13 Spare parts Include pump model and size and its serial number as shown on the nameplate. For each part required include the name and part number as shown on the bill of material. State the quantity required of each part. Provide complete shipping instructions.
  • Page 20 Visit our website for the latest version of this document and more information: www.gouldspumps.com ITT - Goulds Pumps Vertical Products Operation 3951 Capitol Avenue City of Industry, CA 90601-1734 Form IOM.HSU.en-US.2021-10 ©2021 ITT Corporation The original instruction is in English. All non-English instructions are translations of the original instruction.
