Summary of Contents for Raven SCS 360

  • Page 1 Installation & Service Manual SCS 360...
  • Page 2 Manual Rev. B, SCS 360, 6-96 Order: 50, 6-20-96, #016-0159-543...
  • Page 3: Table Of Contents

    INITIAL SYSTEM FIELD TEST ..........................15 PREVENTIVE MAINTENANCE ..........................15 REPLACEMENT PARTS LIST SCS 360 REPLACEMENT PARTS ........................16 1" AND 1 1/2" POLY CONTROL VALVE REPLACEMENT PARTS ..............17 RFM 55 FLOW METER REPLACEMENT PARTS ....................18 WHEEL DRIVE SPEED SENSOR REPLACEMENT PARTS ................19 APPENDIXES 1.
  • Page 4: Symbol Definition

    SYMBOL DEFINITION - Gallons per minute - Centimeters lit/min - Liters per minute - Decimeters dl/min - Deciliter per minute - Meter - Pounds per square inch - Miles per hour - Kilopascal - Kilometers - Gallon per acre km/h - Kilometers per hour lit/ha - Liter per hectare...
  • Page 5: Introduction

    Appropriate cabling is furnished for field installation. The operator sets the target rate (volume per area) to be sprayed and the SCS 360 automatically maintains the flow regardless of vehicle speed or gear selection (within range of selected spray nozzles).
  • Page 6: Installation

    INSTALLATION 1. MOUNTING WHEEL DRIVE SPEED SENSOR The Wheel Drive Speed Sensor consists of four magnets, a switch assembly with cable, and mounting hardware. (Installation instructions for the optional Radar Interface Speed Sensor are included in their shipping carton. See Appendix 7 for the installation instructions for Wheel Drive Speed Sensor with six magnets).
  • Page 7: Mounting The Console And Cabling

    Connect the 2' SCS 360 Console Control Cable to the SCS 212 Console Control Cable and the other end of the SCS 360 Console Control Cable to the back of the SCS 360 Console. (See Figure 4). 3) Run the 24' Flow Control Cable out of the vehicle cab and connect with the Flow Meters.
  • Page 8: Battery Connections

    BATTERY CONNECTIONS FIGURE 5...
  • Page 9: Console Features

    CONSOLE FEATURES IMPORTANT: This Console requires selection of US (acres), SI [hectares], or TU {1,000 sq. ft.} area; SP1 (wheel drive, etc.) or SP2 (radar) speed sensor; and C-Sd (Standard Valve) or C-FC (Fast Close Valve). Console Revision can be determined by the letter stamped in REV box on label.
  • Page 10: Console Calibration

    Appendix 7. 5) Write down this SPEED CAL calibration number for future reference when programming the Console. NOTE: This measurement is critical to the performance of the SCS 360. MEASURE CAREFULLY. Make sure tire is properly inflated before measuring.
  • Page 11: Calculating "Meter Cal

    3. CALCULATING "METER CAL" The Flow Meter calibration number is stamped on the label attached to each Flow Meter. This number is to be used for gallons [liters] per area application. To convert original Flow Meter calibration number from gallons to desired units of measure (oz.
  • Page 12: Calculating "Rate Cal

    5. CALCULATING "RATE CAL" Determine the application rate at which your chemical should be sprayed. Consult with your Dealer to ensure your spray nozzles are capable of applying at this rate. In determining which spray nozzles to use with your sprayer, you must know: 1) Nominal Application Pressure ___ PSI [kpa] 2) Target Application Rate...
  • Page 13: Console Programming

    CONSOLE PROGRAMMING When entering data into the Console, the entry sequence is always the same. (NOTE: DATA MUST BE ENTERED INTO THE FIRST SIX KEYS). Depress the key in which Depress the ENTER key. you wish to enter data. "E" will illuminate in the DATA display.
  • Page 14: Initial Console Programming

    1. INITIAL CONSOLE PROGRAMMING If an entry selection error is made during steps 1-6, place the AUTO/MAN/OFF switch to the OFF position. Depress key and hold while placing the AUTO/MAN/OFF switch to MAN or AUTO. This will "reset" the Console. The DATA display will now show "US".
  • Page 15: Other Displays

    Entering Boom Data. 1. Select desired boom number. 2. Enter boom length as detailed on page 8. 3. If a boom is not needed, enter a "0" for a length. 7) Enter SPEED CAL in key labelled: 8) Enter METER CAL calibration number in key labelled: 9) Enter FLOW RATE gal/acre [lit/ha] target application rate in key labelled: NOTE: A decimal point is displayed automatically.
  • Page 16: Sequence To Activate Data-Lock

    Verify SPEED by depressing key labelled: 6.0 [9.6] will appear in the display. The SELF TEST speed will clear itself when motion of vehicle is detected by the Speed Sensor. A SPEED CAL Value of 900 [230] or greater is recommended when operating in this mode.
  • Page 17: Initial System Field Test

    INITIAL SYSTEM FIELD TEST 1) Drive down field or road at target speed with sprayer booms off, to verify SPEED readout on Console. 2) With water in tank, turn on sprayer and booms and place the AUTO/MAN/OFF switch to AUTO. Increase or decrease speed by one MPH [2 km/h].
  • Page 18: Scs 360 Replacement Parts

    SCS 360 REPLACEMENT PARTS ITEM DESCRIPTION RAVEN PART # Faceplate Assembly 063-0171-165 Display P.C. Assembly 064-0159-535 Spacer, Threaded 305-2540-625 Processor P.C. Assembly 064-0159-544 Connector Plate Assembly 063-0171-167 Screw, 6-32 UNC x 5/16 in. 311-0004-008 Enclosure w/ Inserts 063-0171-135 Screw, 6-32 UNC...
  • Page 19: 1" And 1 1/2" Poly Control Valve Replacement Parts

    1" AND 1 1/2" POLY CONTROL VALVE REPLACEMENT PARTS 063-0159-445 - 1" VALVE 063-0159-446 - 1 1/2" VALVE ITEM DESCRIPTION RAVEN PART # Valve Cover 106-0159-407 #6-32 x 3/4" Lg. Screw 321-0000-256 Motor Assembly 063-0159-409 Woodruff Key 321-0000-062 Coupler Shaft (1" Valve) 019-0159-016 Coupler Shaft (1 1/2"...
  • Page 20: Rfm 55 Flow Meter Replacement Parts

    RFM 55 FLOW METER REPLACEMENT PARTS 063-0159-571 ITEM DESCRIPTION RAVEN PART # Sensor Housing 019-0159-085 #10-32 x 3/4" S.S. Screw 311-0007-037 O-Ring, Viton 219-0002-030 RFM 55 Dual O-Ring XDCR Assembly 063-0159-749 RFM 55 Turbine 117-0159-020 Turbine Hub/Bearing Assembly 063-0359-563 Turbine Stud Assembly...
  • Page 21: Wheel Drive Speed Sensor Replacement Parts

    WHEEL DRIVE SPEED SENSOR REPLACEMENT PARTS ITEM DESCRIPTION RAVEN PART # Red Magnet Assembly, North 063-0159-402 Black Magnet Assembly, South 063-0159-403 Sensor Ass'y (24 ft.) Standard 063-0171-295 Sensor Ass'y (10 ft.) Turf 063-0159-770 Sensor Ass'y (7 1/2 ft.) 063-0171-149 1/2-13 Hex Nut 312-1001-043 1/2"...
  • Page 22: Appendixes

    APPENDIX 1 RIM DRILLING INSTRUCTIONS FOR WHEEL DRIVE SPEED SENSOR MAGNETS On wheels which do not have pre-punched mounting holes, proceed as follows: RIMS WITH FOUR OR EIGHT HOLE STUD PATTERN: Choose stud holes that are opposite each other as shown in Figure 8. Using the center of opposite holes, scribe two lines on the rim web to divide the circumference into four equal parts.
  • Page 23: Procedure To Test Speed Sensor Extension Cables

    APPENDIX 2 PROCEDURE TO TEST SPEED SENSOR EXTENSION CABLES Disconnect extension cable from Speed Sensor Assembly cable. Hold extension cable connector so that keyway is pointing in the 12 o’clock position. 1) 2 o’clock socket is power. 2) 10 o’clock socket is ground. 3) 6 o’clock socket is signal.
  • Page 24: Procedure To Test Flow Meter Cables

    APPENDIX 3 PROCEDURE TO TEST FLOW METER CABLES Disconnect cable from Flow Sensor. Hold Flow Sensor cable so that the keyway is pointing in the 12 o’clock position: 1) 2 o’clock socket is ground. 2) 10 o’clock socket is power. 3) 6 o’clock socket is signal.
  • Page 25: Flow Meter Maintenance And Adjustment Procedure

    APPENDIX 4 FLOW METER MAINTENANCE AND ADJUSTMENT PROCEDURE 1) Remove Flow Meter from Sprayer and flush with clean water to remove any chemicals. 2) Remove flange bolts or clamp from the Flow Meter. 3) Remove the turbine hub and turbine from inside Flow Meter. 4) Clean turbine and turbine hub of metal filings and any other foreign material, such as wettable powders.
  • Page 26: Procedure To Re-Calibrate Flow Meter

    APPENDIX 5 PROCEDURE TO RE-CALIBRATE FLOW METER 1) Enter a FLOW/VALVE CAL number of 10 [38] in the key labelled: 2) Enter a TOTAL VOLUME of 0 in the key labelled: 3) Switch OFF all booms. 4) Remove a boom hose and place in calibrated 5 gallon [19 liter] container. 5) Switch ON appropriate boom switch and MASTER switch.
  • Page 27: Stacking Bracket

    APPENDIX 6 SYSTEM CABLING...
  • Page 28: Six Magnet Wheel Drive Speed Sensor

    APPENDIX 7 SIX MAGNET WHEEL DRIVE SPEED SENSOR Position the six magnets symetrically on the rim of the tire, alternating the magnets in red-black order. To find the new SPEED CAL number, take number found in CALCULATING "SPEED CAL" on page 8 and divide by 3. This is the new SPEED CAL number.
  • Page 31 How Can I Get Service? Bring the defective part and proof of purchase to your Raven Dealer. If your Dealer agrees with the warranty claim, the Dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
  • Page 32 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com atdinfo@ravenind.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
