Playcraft 1205 Assembly Instructions

ACCESS RAMP, BORDER TIMBERS and CONNECTORS
IMPORTANT NOTES: Read First
(A) Use liquid thread lock (such as Loctite
curing) helps to eliminate the common problem of "thread seizure" in stainless steel hardware by serving as a
lubricant during assembly.
(B)
bottom edge of Ramp (Half) using bolts and anchors. Concrete must be allowed to cure completely before using
the equipment (at least 72 hours).
(C) The hardware shown in Figure 3 is the recommendation from the manufacturer and the concrete anchors are
not included with the Equipment. This Figure is provided to show recommended installation of hard surface
mounted Ramps.
Assembly View
Elevation
End View
9/ 26/ 2008 11: 01: 05 AM, Rachel
®
For installation of Ramps over hard surfaces (i.e. concrete sidewalks, slabs, etc.) firmly attach
See Figure 4
Hard Surface Connection
RAMP HALF
(Top)
Manufactured by Krauss Craft, Inc.
www.playcraftsystems.com
) with all threaded hardware.
See Figure 2
Border Timber to Ramp
Assembly Connection
Drill 3/8"Ø Holes in
Ramp, Mark Concrete
4 Pl. each Ramp (Half)
RAMP HALF
Hard Surface Mount Diagram
1205
Page 1 of 3
Liquid thread lock (prior to
See Figure 1
Ramp Halves Connection
See Figure 3
Border Timber to Border
Timber Connection
(Top)
For Customer Service Call
800.333.8519 (U.S.A.) or
541.955.9199 (International)
Top View
Rev A
