Playcraft 1237 Manual

VERTICAL ROCK CLIMBER

IMPORTANT NOTES: Read First

(A) Use liquid thread lock (such as Loctite
curing) helps to eliminate the common problem of "thread seizure" in stainless steel hardware by serving as a
lubricant during assembly.
(B) Refer to Installation Manual for 09 Collars and 11 Socket Clamps assembly instructions.
Figure 1.4
®
) with all threaded hardware. Important: Liquid thread lock (prior to
Manufactured by Krauss Craft, Inc.
www.playcraftsystems.com
FIGURE 1
Vertical Rock Climber
See Installation Manual Sections
09 Collars and 11 Socket Clamps
Figure 1.2
Figure 1.1
Figure 1.3
NOTE: R5 72" Canada Configuration
shown. Other Configurations will vary
slightly, but does not affect the assembly.
For Customer Service Call
800.333.8519 (U.S.A.) or
541.955.9199 (International)
1237
Page 1 of 5
Rev E
9/21/2009
