Playcraft 1206 Installation Instructions

ADA STEPS w/ WALLS
INSTALLATION INSTRUCTIONS
IMPORTANT NOTES: Read First
(A) Use liquid thread lock (such as Loctite
curing) helps to eliminate the common problem of "thread seizure" in stainless steel hardware by serving as a
lubricant during assembly.
(B) Refer to Installation Manual for 09 Collars and 11 Socket Clamps installation instructions.
(C) An appropriate energy absorbing safety surface is required under and around all playground equipment.
Loose fill protective surfacing is shown only as an example for the purpose of this assembly instruction. Other
surfacing material may vary in thickness and/or compression depths. See free publication - The Handbook for
Public Playground Safety, Publication #325 at www.cpsc.gov for the surfacing appropriate for the fall height of
the equipment or consult your surfacing supply representative.
®
) with all threaded hardware. Important: Liquid thread lock (prior to
Figure 1.3
www.playcraftsystems.com
For Customer Service Call
800.333.8519 (U.S.A.) or 541.955.9199 (International)
1206
Page 1 of 4
FIGURE 1
24" ADA Steps w/
Walls
See Installation Manual Sections
09 Collars and 11 Clamps
Figures 1.1 & 1.2
NOTE: R5 24" configuration shown.
Other configurations will vary slightly,
but does not affect the assembly.
Rev K
12/27/2018
