Harmonic ProView 7000 Quick Setup Manual page 7

12. Navigate
Name
1 ƒ BBC
2 ‚ CNN
3 ‚ IBA 2
The Programs menu displays a list of programs available on the input transport stream
and enables you to select the program to be decoded.
The screen displays the program name if the input stream provides an SDT table, the
program ID (decimal number), the program type (TV or Radio) and the program mode
(CAS/scrambled or FTA/free to air).
Only one program can be selected (radio button selection).
13. Navigate
14. Select the CAM slot.
Monitoring the ProView 7000 using the Front Panel
How to monitor the correct operation of the ProView 7000 device.
Status OK
When there are no errors the message
ProView 7000 front panel LEDs are lit green.
The following program information displays on the LCD:
The DVB program selected when SDT is received with the following, name, ID, type and
■
scrambling status.
The MPEG service selected with the ID and scrambling status.
■
Video picture displays on the monitor.
Audio channels left and right give correct sound, synchronized to the picture that is displayed.
© 2010 Harmonic Inc.
How to Configure and Monitor the ProView 7000
Root > 2 Decoding > 1 Configuration> 3 Programs
Root > 2 Decoding > 1 Configuration> 4 Descrambling > 1 CAM Selection
Status OK
.
ID Type
4301 TV
4302 TV
4308 AUDIO
displays on the LCD and the two
STATUS OK
BBC
ID: 4301
7
Mode
CAS
CAS
FTA
.
TV CAS
ProView 7000, v.2.3, Rev. A
