Harmonic ProView 7000 Quick Setup Manual page 11

3. To descramble a program:
i Right-click a program in the Multiplex & Decoding Output box.
ii Select
The Program Properties dialog displays.
iii Mark the Descramble with checkbox.
iv Select a CAM slot.
v Click
4. To map a different port or additional ports to an MPEG Multiplex In:
i Drag a Port from the Physical Input box to an MPEG Multiplex In in the Multiplex In
box.
A confirmation dialog displays.
ii Click
© 2010 Harmonic Inc.
How to Configure and Monitor the ProView 7000
.
Properties
.
Apply
to create the mapping.
Yes
11 ProView 7000, v.2.3, Rev. A
