FOODSAFE IL INSTALLATION MANUAL
STATUS
UV LAMP 1
UV LAMP 2
UV SYSTEM 'ON'
/ SISTEMA UV 'ENCENDIDA'
UV LAMP TO BE REPLACED
/ LÁMPARA UV QUE SER REEMPLAZADO
UV LAMP FAILURE
/ FALLOS DE LA LÁMPARA UV
NO POWER (LED OFF)
/ NO HAY ENERGIA (LED APAGADO)
QUESTIONS ON INSTALLATION?
CALL SANUVOX AT 1-888-726-8869
Version 06/2012
Advertisement
Table of Contents
Related Manuals for Sanuvox FOODSAFE IL
Summary of Contents for Sanuvox FOODSAFE IL
- Page 1 FOODSAFE IL INSTALLATION MANUAL STATUS UV LAMP 1 UV LAMP 2 UV SYSTEM ‘ON’ / SISTEMA UV 'ENCENDIDA' UV LAMP TO BE REPLACED / LÁMPARA UV QUE SER REEMPLAZADO UV LAMP FAILURE / FALLOS DE LA LÁMPARA UV NO POWER (LED OFF)
- Page 2 FOODSAFE IL KIT INCLUDES STATUS UV LAMP 1 UV LAMP 2 UV SYSTEM ‘ON’ / SISTEMA UV 'ENCENDIDA' UV LAMP TO BE REPLACED / LÁMPARA UV QUE SER REEMPLAZADO UV LAMP FAILURE / FALLOS DE LA LÁMPARA UV NO POWER (LED OFF) / NO HAY ENERGIA (LED APAGADO) A.
- Page 3 Before installing the FoodSafe IL or performing maintenance or service on the UV system, turn off the unit's main power switch. Electrical shock can cause injury or death. There may be more than one disconnect switch. Never expose eyes or skin to ultraviolet light from any source.
- Page 4 8. To protect users from direct exposure to the ultraviolet rays, a Limit Switch may be field supplied. The Limit Switch will shut down operation to the UV system should the access door be opened. A Limit Switch is available from Sanuvox (part# MSCSWC14).
- Page 5 (approx. 3/4"). Wiring to POWER 13. The FoodSafe IL is available in different voltages. With cover removed, pull the white (neutral) and black (hot) from the round knock-out at the bottom of the ballast box. CONNECT TO POWER using the included ORANGE wire connectors.
- Page 6 IL40-G: Lamp Length 40” long 120 volt (IL40/220-G:230 Volt) IL50-G: Lamp Length 50” long 120 volt (IL50/220-G:230 Volt) Use only specified Sanuvox UV Lamps with this UV IL60-G: Lamp Length 60” long 120 volt (IL60/220-G:230 Volt) system. Other UV Lamps may plug into the accessory, but they should not be used.
