WHOLE HOME UV AIR PURIFIER & ODOR REMOVAL SYSTEM
READ AND SAVE THESE SAFETY INSTRUCTIONS BEFORE USING THIS PRODUCT.
Read and follow all instructions contained in
this manual before using the product. Failure
to comply with these instructions may result
in personal injuries or damage to the unit or
system.
1. Installation and servicing of air conditioning
and related equipment can be hazardous due
to systems pressure and electrical components.
Only trained and qualified service personnel
should install, repair or service equipment.
2. Untrained personnel can perform basic
maintenance functions such as replacing
lamp(s) and/or filter(s). All other operations
should be performed by trained service
personnel.
3. When working on the unit or system, observe
precautions in the literature, tags and labels
attached to the unit or system, and all other
safety precautions considered as best practices
in the HVAC industry.
Installation Date: _______________
Installer Contact Info.: _________________________________________
SR MAX
Residential Model

IMPORTANT SAFETY INSTRUCTIONS

4. When
applicable,
comprise more restrictive installation and/or
certification requirements. The afore mentioned
requirements prevail on those of this document
and the installer agrees to conform to these at
his own expense.
5. Follow all the safety instructions outlined in this
document and respect all local and national
codes applicable.
6. Never expose eyes or skin to ultraviolet light
from any source. Therefore, before installing
or performing maintenance on the unit or
system, TURN OFF AND DISCONNECT the
unit or system from all power sources (there
may be more than one switch to disconnect).
CAUTION: Electrical shock may cause
personal injuries or possibly death.
7. UV rays may destroy certain types of filters
(polymer or plastic); please keep the unit or
system light away from shining directly on
plastic.
Sanuvox Technologies Inc, © 2019 All rights reserved. October 2019 EN v.1
local
regulation
may
8. When installing or performing maintenance on
the UV unit or system, it is recommended to
wear safety glasses and gloves. In order to
avoid reduced performance of lamp(s), do not
touch lamp glass without gloves.
9. UV lamps contain a small quantity of mercury:
if a lamp breaks, clean and dispose of with
care. UV lamps can be disposed/recycled after
use, as any other fluorescent lamps. Contact
and follow your local and national authorities'
specific instructions.
10. Use only specified SANUVOX branded
replacement UV lamps with your unit or
system. Use of any other lamps will void your
warranty and can result in damage to the unit,
system and/or lamp(s).
11. Most UV units or systems are not waterproof.
DO
specified otherwise.
Installed by: _________________
Instruction Manual
NOT
INSTALL
OUTDOORS
SAVE THESE INSTRUCTIONS
unless

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR MAX and is the answer not in the manual?

Questions and answers

Summary of Contents for Sanuvox SR MAX

  • Page 1: Important Safety Instructions

    SAVE THESE INSTRUCTIONS in the HVAC industry. plastic. Installation Date: _______________ Installed by: _________________ Installer Contact Info.: _________________________________________ Sanuvox Technologies Inc, © 2019 All rights reserved. October 2019 EN v.1...
  • Page 2: Table Of Contents

    What you will need Internal Components Problems & Solutions Table A. Step by Step SR Max Ballast Box Opening B. Step by Step UV Lamp Continuity Test C. Step by Step LED Display Circuit Board Bypass (Ballast or Circuit Board Validation) D.
  • Page 3: About The Product

    How it Works Contaminated air enters the SR Max parallel to the UV ‘J’ Lamp, thus increasing contact time with the UV energy. The Turbulator spins and mixes the air around the UV ‘J’ Lamp. First, the UVV oxidizing section of the lamp, boosted by Cobalt, destroys chemicals and odors.
  • Page 4: Setup & Installation

    CAUTION: Handle your product with care to avoid breaking parts. Make sure you have a free and safe space to unpack, install and setup your product. Confirm you have access to the necessary power source for the product requirements (see unit or system label). If you have any questions regarding the installation instructions, call SANUVOX at 1-888-726-8869. What’s included The SR Max with its turbulator, a UV lamp and a basic installation kit.
  • Page 5 Instruction Manual for SR Max STEP 3 3. To install the UV lamp, release the reflecting tube by removing the 2 screws on each side. STEP 4 4. While holding the porcelain end-cap (with 4 pins), carefully push the white connector onto the four pins. The plug is designed so that it can only be installed one way.
  • Page 6 Use preferably 3 top and 3 bottom holes of the frame to insert the screws. STEP 10 10. Finalize the SR Max installation in the duct by placing the unit into the frame, guided with the alignment pins. STEP 11 11.
  • Page 7: Operation

    How to Operate your Product The SR Max is an automatic unit: once it’s installed and plugged in, simply press the power switch to turn it ON. Wait approximately 40 seconds for the startup phase to be done and enjoy clean air in your home! CAUTION: The suggested operating temperature range is 10 to 50°C (50 to 122°F).
  • Page 8: How To Activate "Airflow Detection" Function (Optional)

    How to Activate “Airflow Detection” Function (Optional) In “Default Mode” ( power is ON and unit operates normally), the SR Max lamp is always lit. If you activate the “Airflow Detection” function, the thermistor will detect airflow and automatically turn the lamp ON or OFF as needed.
  • Page 9: How To Reset Your Product And Its Lamp Timer

    Instruction Manual for SR Max How to Reset your Product and its Lamp Timer After installing a new lamp, make sure the timer function is reset. Step by Step Product and Lamp Timer Reset STEP 1 1. To reset the lamp timer the unit needs to be powered and turned ON.
  • Page 10: Maintenance

    How to Replace Lamp(s) Replacing lamps on the SR Max is quick and easy. Simply turn off the power source, remove unit from duct, remove and dispose of old lamp, replace with new Sanuvox branded UV lamp, replace unit in duct and turn power source back on. See below for detailed step by step instructions.
  • Page 11 UV lamp. STEP 9 9. Once the new UV lamp is installed, replace the SR Max into duct. Then, reset your product and its lamp timer (see page 9). www.sanuvox.com...
  • Page 12: How To Clean Your Product

    ULTRAVIOLETS: UVV & UVC The UVC (254 nm) and UVV (185 nm) light produced by Sanuvox UV units and systems are the same two UV wavelengths produced by the Sun. The UVC wavelength attacks the micro-organisms on a molecular level deactivating and destroying the contaminants, while the UVV wavelength degrades the chemicals and odors.
  • Page 13: Problems & Solutions Table

    - Turn the fan ON or set a higher speed airflow. to increase airflow circulating in the ductwork. - Reposition the SR Max in the ductwork where the airflow is unobstructed. - If airflow is not sufficient to be detected by thermistor, remove airflow detection.
  • Page 14: Step By Step Sr Max Ballast Box Opening

    (4 corners) that hold it to the frame. STEP 2 2. Place the SR Max on a flat surface and remove the 2 screws on each side that attach the cover to the ballast box. B. Step by Step UV Lamp Continuity Test STEP 1 1.
  • Page 15: Step By Step Led Display Circuit Board Bypass (Ballast Or Circuit Board Validation)

    C. Step by Step LED Display Circuit Board Bypass (Ballast or Circuit Board Validation) 1. Open the SR Max ballast box : see step by step instructions of the Ballast Box Opening on page 14 (A). STEP 2 2. Unplug the ballast black wire from the circuit board.
  • Page 16: Warranty

    This warranty applies only to the original purchaser of this product from the original date of purchase. At its option, SANUVOX will repair or replace this product if it is found to be defective in material or workmanship.
