6、Io Sheet - MecPower Tecway Cyclontron Operation Manual

TSL-03-38
25
Input：
JP2
INPUT CONTENT
JP2_26 1P coin
JP2_25 1P confirm button
JP2_24 1P refund feedback
JP2_23 1P banknote machine
JP2_22 2P coin
JP2_21 2P confirm button
JP2_20 2P refund feedback
JP2_19 2P banknote machine
JP2_18 3P coin
JP2_17 3P confirm button
Output：
JP5 Note:JP5 is for UNL2803 output
OUTPUT CONTENT
JP5_1
1P ticket driver
JP5_2
1P Absence indicator
JP5_3
1PLOGO spot light R
JP5_4
JP5_5
2P ticket drive
JP5_6
2P Absence indicator
JP5_7
2P LOGO spot light R
JP5_8
Arrow
6、IO Sheet
JP2
INPUT CONTENT
JP2_16 3P refund feedback
JP2_15 3P banknote machine
JP2_14 Test button
JP2_13 Service button
JP2_12 Repair button
JP2_11
JP2_10
JP2_9
JP2_8
JP2_7
OUTPUT CONTENT
JP5_9
3P ticket driver
JP5_10
3P absence indicator
JP5_11
3P LOGO spot light R
JP5_12
JP5_13
JP5_14
JP5_15
JP5_16
24
Fluorescent Green Organic Tablets
2019/3/1
JP2
INPUT CONTENT
JP2_6
JP2_5
JP2_4
JP2_3
JP2_2
OUTPUT CONTENT
JP5_17
JP5_18
JP5_19
JP5_20
JP5_21
JP5_22
JP5_23
JP5_24
3
JP3
INPUT CONTENT
JP3_24
JP3_23
JP3_22
JP3_21
JP3_20
JP3_19
JP3_18
JP3_17
JP3_16
OUTPUT CONTENT
