Mocka Eclipse Assembly Instructions Manual page 5

Eclipse Two Door Cabinet
Assembly Instructions
7
B
B
B
A
A
4
Attach panel [2] to panels [3] and [4] with 4x dowels (A) and secure
with 4x screws (B). Tighten with a screwdriver.
