Installation & Maintenance Manual
PL42VO
28,000 btu/hr Natural Gas or Propane Gas
PL60VO
47,000 btu/hr Natural Gas or Propane Gas
Outdoor Gas Fireplace
• The installation of this fireplace must be done by a qualified and
®
• Check local codes and read all instructions prior to installation.
• Installer: leave this manual with the appliance.
C
US
• Consumer: retain this manual for future reference.
certified gas appliance installer.
DANGER
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
WARNING
Do not store or use gasoline, or other flammable vapors and
liquids, in the vicinity of this or any other appliance.
A propane-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Read the installation, operating, and maintenance instructions
thoroughly before installing or servicing this equipment.
WARNING: For Outdoor Use Only.
XG0219 - 170829
