Miscellaneous
Delay of output signal after start-up
After start-up or a power failure the controller's functions can be delayed so that over-
loading of the electricity supply network is avoided.
Here you can set the time delay.
Digital input signal - DI1
The controller has a digital input 1 which can be used for one of the following func-
tions:
Off: The input is not used
1) Status display of a contact function
2) Door function. When the input is open it signals that the door is open. The refrig-
eration and the fans are stopped and light switched on. When the time setting in
"A04" is passed, an alarm will be given and refrigeration will be resumed (o89).
3) Door alarm. When the input is open it signals that the door is open. When the time
setting in "A04" is passed, there will be alarm.
4) Defrost. The function is started with a pulse signal. The controller will register when
the DI input is activated. The controller will then start a defrost cycle.
5) Main switch. Regulation is carried out when the input is short-circuited, and regula-
tion is stopped when the input is put in pos. OFF.
6) Night operation. When the input is short-circuited, there will be regulation for
night operation.
7) Thermostat band changeover. Switch to thermostat 2 (r21).
8) Separate alarm function. Alarm will be given when the input is short-circuited.
9) Separate alarm function. Alarm will be given when the input is opened. (For 8 and
9 the time delay is set in A27)
10) Case cleaning. The function is started with a pulse signal. See also description on
page 5.
11) Forced refrigeration at hotgas defrost when the input is short-circuited.
12) Night cover
If the controller is built into a network with data communication, it must have an
address, and the master gateway of the data communication must then know this
address.
The address is set between 0 and 240, depending on the system unit and the selected
data communication. If the system unit is gateway type AKA 245, the version must be
6.20 or higher.
The address is sent to the gateway when the menu is set in pos. ON
IMPORTANT: Before you set o04, you MUST set o61. Otherwise you will be transmit-
ting incorrect data.
(The function is not used when the data communication is MODBUS)
Access code 1 (Access to all settings)
If the settings in the controller are to be protected with an access code you can set a
numerical value between 0 and 100. If not, you can cancel the function with setting 0.
(99 will always give you access).
Sensor type for S3, S4, S5, S6
Normally a Pt 1000 sensor with great signal accuracy is used. But you can also use a
sensor with another signal accuracy. That may either be a PTC sensor (1000 ohm at
25°C)
All the mounted sensors S3-S6 must be of the same type.
Max. standby time after coordinated defrost
When a controller has completed a defrost it will wait for a signal which tells that the
refrigeration may be resumed. If this signal fails to appear for one reason or another,
the controller will itself start the refrigeration when this standby time has elapsed.
Select signal for the display S4%
Here you define the signal to be shown by the display.
S3, S4, or a combination of the two.
With setting 0% only S3 is used. With 100% only S4.
Pe. Working range for pressure transmitter - min. value
Pe. Working range for pressure transmitter - max. value
Refrigerant setting (only if "r12" = 0)
Before refrigeration is started, the refrigerant must be defined. You may choose be-
tween the following refrigerants
1=R12. 2=R22. 3=R134a. 4=R502. 5=R717. 6=R13. 7=R13b1. 8=R23. 9=R500.
10=R503. 11=R114. 12=R142b. 13=Userdefined. 14=R32. 15=R227. 16=R401A.
17=R507. 18=R402A. 19=R404A. 20=R407C. 21=R407A. 22=R407B. 23=R410A.
24=R170. 25=R290. 26=R600. 27=R600a. 28=R744. 29=R1270. 30=R417A.
31=R422A
Warning: Wrong selection of refrigerant may cause damage to the compressor.
Other refrigerants: Here Setting 13 is selected and then three factors -Ref.Fac a1, a2
and a3 - via AKM must be set.
20 Manual RS8EN502 © Danfoss 02-2010
Miscellaneous
o01 DelayOfOutp.
o02 DI 1 Config.
Definition takes place with the nu-
merical value shown to the left.
(0 = off )
DI state
(Measurement)
The DI input's present status is shown
here. ON or OFF.
o03
o04
o05 Acc. code
o06 SensorConfig
Pt = 0
PTC = 1
o16 Max HoldTime
o17 Disp. S4%
o20 MinTransPres
o21 MaxTransPres
o30 Refrigerant
AK-CC 550
