AV Cart 20
COMPONENT CHECKLIST
A
Column (x1)
E
F
Left Display
Right Display
Bracket (x1)
Bracket (x1)
L
M
Base Leg Cover
Cable
Right (x1)
Cover
(x2)
M-A
M-B
M-C
M5X14
M6X14
M6X30
Screw
Screw
Screw
(x4)
(x4)
(x4)
IMPORTANT INFORMATION
!
Please ensure this product is installed as per these installation instructions.
!
The manufacturer accepts no responsibility for incorrect installation.
!
Failure to assemble this product correctly may cause serious injury/death during or following installation.
!
This product should only be installed by professional installers of good mechanical aptitude, who fully understand these instructions and the
consequences of incorrect installation.
!
Do not over tighten screws.
!
Two person installation is recommended.
!
Product not suitable for use outdoors.
!
After installation is complete check to verify that AV Cart is secure and safe for use.
!
Curved monitors, deep devices (such as all-in-one PCs), VESA mounted accessories (such as mini PC brackets and mounts), and offset VESA
locations exert additional leverage that can exceed the capacity of the mount even though the monitor weight may be within the stated range.
Please contact Atdec if you would like further information.
!
WARNING! Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on
the cart may encourage a child to climb on the cart and as a result the cart may tip over on to the child.
B
Base Leg (x2)
G
H
AV Shelf
AV Shelf
(x1)
Bracket (x1)
N
O
P
M6X50
M6X35
M6X16
Washer
Screw
Screw
Screw
(x8)
(x4)
(x4)
(x11)
M-D
M-E
M8X30
M8X50
Screw
Screw
(x4)
(x4)
C
Base Crossbar (x1)
Rail (x1)
I
J
Column Base
Castor
Base Leg Cover
Cover (x1)
(x4)
Q
R
S
Column Top
5mm Allen
Cover (x1)
Key(x1)
M-F
M-G
Multi
Small
Washer
Spacer
(x4)
(x8)
Installation Guide
D
REQUIRED TOOLS
K
• Phillips Head Screwdriver
Left (x1)
CAPACITY
T
M8 + M10
Wrench
DISPLAY
(x1)
0 - 20kg (0 - 44lb)
32" - 55"
M-H
SHELF
Large
0 - 5kg (0 - 11lb)
Spacer
(x8)
AD-TVC-20
AD-TVC-20 Page 1 of 4
