Atdec VF-AT-W Datasheet

Focus
| Wall mounted monitor arm
The Visidec Focus VF-AT-W wall mount combines ergonomic functionality
with effortless adjustability. Its sleek and contemporary design features
an elegant polished aluminium finish that will add style to any home,
office or retail environment. The articulated arm allows for an attached
screen to be pulled out from the wall and subsequently folded back. The
viewing angle can be adjusted and the screen orientation rotated from
landscape to portrait. Height adjustment is also possible while cables
are managed internally for a clean and uncluttered workspace.
Product key features:
Sleek and contemporary design
Durable materials (die-cast anodised aluminium)
Arm maximum reach: 454mm (17.8")
Display height adjustment range: 128mm (5")
Comes with all mounting hardware
FlexiStar™ mechanism to support 75x75 and
100x100 VESA mounting hole patterns
Adjustable tilt: 70º up
and 70º down
®
VF-AT-W
Portrait to landscape
rotation
Unique locking
mechanism supports the
screen weight during
height adjustment
Mounting hole pattern:
75x75mm & 100x100mm mounting
(100x200mm optional)*
Maximum weight carrying capacity:
8kg (17.5lbs)
Offers a wide range of
movement via 3 pivot points
Advanced
cable management
Tool-less height
adjustment
Atdec Global
®
Atdec North America
Adjustable pan: 90º
left and 90º right
www.atdec.com.au
www.atdec.com
