Atdec AWM-A13H Installation Manual

AWM 130 Arm Heavy Duty
COMPONENT CHECKLIST
A
Heavy Duty Tilt Head
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! Do not remove or throw away the plastic sleeve on the channel clamp.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series products except the Wall Channel products (including AWM-W6
and AWM-W35)
! Curved monitors, deep devices (such as all-in-one PCs), VESA mounted accessories (such as mini PC brackets and mounts),
and offset VESA locations exert additional leverage that can exceed the capacity of the mount even though the monitor
weight may be within the stated range. Please contact Atdec if you would like further information.
Screw
M4x25mm
(x4)
B
Channel Clamp
(x1)
Spacer
(x4)
C D E
Screw Screw
M4x16mm M4x12mm
(x4) (x4)
F G H
Security 4mm
screw Hex Key
(x4) (x1)
Installation Guide
AWM-A13H
REQUIRED TOOLS
• Phillips Head Screwdriver
WEIGHT RANGE
Flat Monitors
0 - 18kg
(0 - 40lbs)
Curved Monitors
0 - 12kg
(0 - 26.5lbs)
Monitor weight should be within
the weight range of all modular
elements that make up the complete
monitor mounting solution.
AWM-A13H Page 1 of 3
