Frama Fx 7 Series Quick Installation Manual

Fx Series 7
Quick Installation Guide
Machine components:
Machine Base
Feeding Table
1
Unpack all components from the box, remove packaging
and any transit tape.
5
Lift machine slightly on the left hand side and align the hooks to attach the feeding table
attach the catch tray (c) to the right hand side of the machine.
9
Installation Process
1 LAN
OK
Select LAN and press to test connection type.
Catch Tray
Back of the machine
2
Lift the cover of the machine to reveal the
ink cartridge (i) and meter (j) locations.
6
(b) – Attach the weighing platform
shelf (if applicable)
10
Installation Process
Press the 'Next' to start the
Online service
declaration.
Next
Follow the steps on screen to complete the
procedure.
Shelf
Weighing Platform
3
Place the meter (j) into the meter compartment and push backwards
until it fits securely into position.
7
(e) and Connect the weighing platform connector
(d). at the back of the machine. Then connect the LAN cable
power cable (h)
11
Your machine is now ready
to use. Please turn over
for your Quick Start Guide.
LAN Cable
Weighing Platform
Cable
4
Insert the ink cartridge
'LOCK' stickers facing upwards. Push the ink cartridge
of the machine until you hear a 'click' - close the cover of the machine.
(f) into a COM PORT
(g) and
to either side of the machine.
For more information or if you experience any
issues, please visit :
Power Cable
Ink Cartridge Postage Meter
(PSD)
Remove tabs from
print heads before
inserting into unit!
(i) at an angle into the machine with the 'TOP' and
(i) towards the back
8
Turn on the machine using the switch behind the
power cable (h) and follow the steps on screen.
www.frama.co.uk/Fx7
