X931
MODEL V9317H SERIES
ENVIRONMENTAL HOUSING
Copyright © 2000 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon part number 8006-8931-03-01
Section 6 Rev 900

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V9317H Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Vicon V9317H Series

  • Page 1 Copyright © 2000 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788 TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com...
  • Page 5: Table Of Contents

    Contents Introduction ............................5 Installation............................7 Unpacking and Inspection ........................7 Inspection For Visible Damage......................7 Inspection For Concealed Damage ....................... 7 Mounting the Housing.......................... 7 Camera Installation ..........................8 Wiring the Unit............................. 9 Operation............................11 Maintenance ............................11 Shipping Instructions........................12 Technical Information ........................13 Contents •...
  • Page 6 ii • • X931 Rev 900 V9317H...
  • Page 7 Use only with a mounting accessory recommended by Vicon, or sold with the video product. Any mounting of the video product should follow Vicon’s instructions, and a mounting accessory recommended by Vicon should be used.
  • Page 8 Vicon or that have the keep from touching such power lines or circuits as same characteristics as the original part. Unauthorized contact with them might be fatal.
  • Page 9: Introduction

    Introduction The information in this instruction manual covers the installation and maintenance of the V9317H Series of Environmental Housings. This unit should be installed by a qualified technician using approved materials in accordance with national, state and local codes. Read these instructions through completely before attempting installation.
  • Page 10 NOTES 6 • • Introduction X931 Rev 900 V9317H...
  • Page 11: Installation

    Installation Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver the equipment in the same condition as it left the factory. Inspection For Visible Damage Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the carrier’s freight bill.
  • Page 12: Camera Installation

    Figure 1 Mounting Plate Dimensions Camera Installation 1. Disengage the two (2) side latches to open the cover. 2. Remove the camera mounting plate from the housing by loosening the four (4) Phillips head screws used to secure the plate. Slide the plate off the screws using the key slot holes. 3.
  • Page 13: Wiring The Unit

    5. Place the camera and plate back into the housing in a position where the lens just clears the window for the greatest angle of view. 6. Tighten the four (4) mounting plate screws to secure it in place. Wiring the Unit The V9317H housing is provided with one liquid-tight compression fitting and one ½...
  • Page 14 NOTES 10 • • Installation X931 Rev 900 V9317H...
  • Page 15: Operation

    Operation The wiper units should be operated on an intermittent duty cycle by a switched line. The blade on the wiper should be kept clean by occasionally wiping with a damp cloth. Maintenance The housing needs no maintenance other than the occasional cleaning of the window, using plain soap and water.
  • Page 16: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.
  • Page 17: Technical Information

    Technical Information ELECTRICAL Input Voltage: V9317HC-SB, V9317HC-SHB, V9317HC-WHB: 120 VAC. V9317HC-SB-24, V9317H-SHB-24, V9317H-WHB-24: 24 VAC. V9317HC-SB-230, V9317HC-SHB-230, V9317HC-WHB-230: 230 VAC. Power Consumption: Housing with blower: 16 W Housing with heater and blower: 76 W (60 W for heater and 16 W for blower). Housing with blower, heater, wiper: 79 W (60 W for heater, 16 W for blower and 3 W for wiper).
  • Page 18 Construction: End Caps: plastic, light gray. Housing: aluminum, painted light gray. Window: 0.125 in. thick lime glass. Clear Window Area: 4.0 in. (W) x 2.9 in. (H) (10.2 x 7.4 cm). Cable Access: One liquid tight compression fitting and one ½-in. conduit fitting located at bottom of rear base.
