fantastic furniture Java Console Table Manual page 16

Step 19
You will need
2 x Flat
2 x Screws
Washers (H9)
25mm (H14)
2 x Wall Straps
Phillips Head
(H13)
Screwdriver
(P5)
H14
Fix 2 x wall straps (H13) to top panel (P1) with 2 x screws (H14)
and 2 x flat washers (H9) as shown, using a phillips head screwdriver.
Step 20
You will need
2 x Flat Phillips Head
Washer (H9) Screwdriver
Seek advice from a qualified
trades person on how to
attach this wall strap to
your specific wall.
Screw and wall plug are not included.
Please use appropriate fixtures for your wall.
With assistance, move the console table to the final position.
Attach the wall straps to the wall.
Make sure they are firmly attached and secure.
fantasticfurniture.com.au
H14
H13
(P1)
H9
Two People
Required
H13
H9
(P5)
H14 H9
We strongly recommend
that this product is permanently
fixed to the wall
or other suitable surface.
(P1)
H13
Wall
H9
Screw
Page 16
