CPU OverClocking Configuration
EIST
EIST,the full name of "Enhanced Intel SpeedStep Technology"，It is an
intelligent downfrequency technology， It can automatically adjust the voltage
and frequency of the processor according to different system workload，to
reduce electricity consumption and heat。The set values are: Disabled、
Enabled。
Turbo Boost
Turbo Boost， it is Turbo Mode， it is a power management technology based
on Nehalem architecture, through the analysis of the current situation of the
load of CPU, intelligent completely shut down some not to use the core, the
core is to use energy, and make them run at a higher frequency, to further
enhance the performance; instead, the need for multiple core, dynamic and
open the corresponding core intelligent adjustment, frequency. Thus, the
core operating frequency can be tuned higher without affecting the TDP of
the CPU。The set values are:Disabled、 Enabled.
Power Limit 1-4 Override
CPU power limit 1-4。
Boot performance Mode
Set boot performance mode.
The set values are:Max Non-Turbo Performance、Max Battery、Turbo
Performance.
TDP LOCK
Set TDP power limit.The set values are:Disabled、 Enabled.
CPU Ratio
Set CPU Ratio.
1-6Core Ratio Limit Override
This setup of CPU core frequency technology, you can modify the frequency
of the target frequency, note that the 1-6 here is not 1-6 per core, but the
number of cores. The less the number of cores involved, the higher the
frequency.
