Jorvic - CD Unit
Assembly Instructions - Important: Retain these instructions
In order to prevent overturning, this product must be
used with the 2 wall attachment devices provided
Dimensions
Width - 90.5cm
Depth - 24cm
Height - 150.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0330 016 1114
For any other queries please contact the Customer Helpline on: 0345 640 2020
for future reference
WARNING!
More help is available throughout this
booklet by scanning in the QR codes
or typing in the links
620/5555
MADE IN
BRITAIN
Issue 4 - 23/01/20
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Home Jorvic 620/5555
Summary of Contents for Argos Home Jorvic 620/5555
- Page 1 Jorvic - CD Unit Assembly Instructions - Important: Retain these instructions 620/5555 for future reference WARNING! In order to prevent overturning, this product must be used with the 2 wall attachment devices provided Dimensions More help is available throughout this Width - 90.5cm booklet by scanning in the QR codes Depth - 24cm...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Parts of the assembly will be • We do not approximately 28kgs. easier with 2 people. recommend the Please lift with care. use of power •... - Page 3 Components - Panels Please check you have all the panels listed below (DF-00021892) (90.3 x 16.9cm) Base (DF-00021893) (90.3 x 23.9cm) Middle Shelf (DF-00021894) (87 x 16.5cm) 1 Left Side 2 Right Side (DF-00021890) (DF-00021891) (147.5 x 16.7cm) (147.5 x 16.7cm) Bottom Upright (DF-00021896) (62.4 x 16.3cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wooden dowel x 24 Wooden dowel x 28 Metal dowel (F40)
- Page 5 Assembly Instructions Step 1 Prepare the 2 top Finished uprights front edge Tap 2 short wooden 10mm dowels into each of the top uprights shown. Note: The short wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
- Page 6 Assembly Instructions Step 4 Prepare the middle shelf Finished front edge Insert 4 large locking cam nuts into the middle shelf shown. Step 5 Finished front Fit the middle shelf edge Position the middle shelf onto the assembly as shown. Tap 4 long wooden dowels through the...
- Page 7 Assembly Instructions Step 7 Finished front Fit the other bottom edge upright 8mm holes Fit the other bottom upright to the assembly. Tap 4 long wooden 5.5mm holes dowels through the bottom upright into each of the shelves Step 8 Finished front Fit the bottom upright...
- Page 8 Assembly Instructions Step 10 Finished front edge Fit the shelves Push the shelves onto the top uprights Finished and bottom uprights front edge as shown. Note: Make sure that all of the shelves have the finished front edge pointing upwards. Step 11 Prepare the left side Screw 2 metal dowels...
- Page 9 Assembly Instructions Step 12 Fit the left side Push the left side onto the assembly. Finished Use a screwdriver to front edge tighten the 2 large locking cam nuts fitted to the middle shelf Note: Turn the large locking cam nuts far as they will go - more than 1/2 a turn.
- Page 10 Assembly Instructions Step 14 Finished front edge Fit the right side Push the right side onto the assembly. Use a screwdriver to tighten the 2 large locking cam nuts fitted to the middle shelf Step 15 Fit the base Finished Fit the base to the front edge...
- Page 11 Assembly Instructions Step 17 Finished front edge Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 2 large locking cam nuts fitted at the top of the left side and right side Carefully turn the assembly over for the Warning: The next step.
- Page 12 Assembly Instructions Step 19 WARNING! Fit the 2 overbalance In order to prevent overturning protector kits this product must be used with the 2 wall attachment devices provided To prevent possible overbalancing this unit must be secured to a See the next page for a guide suitable wall by fitting of to wall mounting and fixings the 2 overbalance...
-
Page 13: A Guide To Wall Mounting & Fixings
A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit. - Page 16 ALR3362...
