3' Lavendon End Opening Ottoman Bed
Assembly Instructions
hygena
Dimensions (3')
Length - 203cm
Width - 100cm
Height - 82cm
Important
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Please keep for future reference
4158714
5748848
7096945
7208757
7349252
Issue 1 - 03/05/17
Advertisement
Related Manuals for Argos Home Hygena 4158714
Summary of Contents for Argos Home Hygena 4158714
- Page 1 3' Lavendon End Opening Ottoman Bed Assembly Instructions Please keep for future reference 4158714 5748848 hygena 7096945 7208757 7349252 Dimensions (3') Length - 203cm Width - 100cm Height - 82cm Important Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Issue 1 - 03/05/17...
- Page 2 Safety and Care Advice Assemble the item as close We do not Check you have all the recommend the components and tools listed on to its final position (in the same use of power pages 2, 3 and 4. room) as possible. drill/drivers for Remove all fittings from the Assemble on a soft level...
- Page 3 0345 6400 800 INSIDE INSIDE FRONT INSIDE Hinge Mechanism (x 1 pair) NOTE: PISTON ATTACHED Fabric base x 1 Ottoman end frame (Footboard) x 1 (1960 x 970mm) (910 x 118mm) Ottoman end frame (Headboard) x 1 Stretcher x 1 (910 x 118mm) (940 x 25mm) NOTE: EXTRA HOLES...
- Page 4 0345 6400 800 Ottoman frame (Sides) x 2 Bentwood slats x14(900*9*53mm) (1822 x 30mm) Slat caps x 28 (5.5mm) Mattress support Ottoman frame support x 1...
- Page 5 Components - Fittings 0345 6400 800 45mm M8 Bolt x 8 25mm M8 Bolt x 12 30mm M8 Bolt x 18 50mm M5 Wood screw x 16 17mm Flat washer x 38 Nut x 6 12mm Spring washer x 16 30mm M4 Wood screw x 4 5mm Allen key x 1 Spanner x 1...
- Page 6 Assembly Instructions Preparing headboard and footboard a: With help, carefully place headboard footboard flat onto the floor with the fixing holes facing up as shown. Note: Ensure the floor is suitably clean to protect the headboard and footboard from damage. Loosely insert bolts fixings into...
- Page 7 Assembly Instructions Attaching side rails With help, raise headboard into the standing position. Hang the metal brackets on the end of the side rails , over the bolts in the headboard Holes at headboard Note: Ensure the holes on the inside of each side rail are located at the headboard end as shown.
- Page 8 Assembly Instructions Attaching cover With help, carefully turn the frame onto its side. Warning: The frame is heavy. Lift with care. Attach fabric base the underside of the frame using the velcro strips on all 4 sides. Attaching feet Assemble feet to the underside of the headboard and footboard...
- Page 9 Assembly Instructions Attaching folding hinges With help, carefully return the frame to the standing position. Secure hinges side rails using fixings as shown. Note: Ensure the hinges are fitted the correct way around as shown. Assembling ottoman frame Loosely assemble ottoman frame components together as shown.
- Page 10 Assembly Instructions Assembling ottoman frame With help, carefully turn the frame over. Note: The frame is heavy. Lift with care. Assemble mattress support brackets end frame (headboard end) using screws Aligning ottoman frame Ensure hinges folded flat as shown. Warning: Keep hands clear of the folding areas at all times.
- Page 11 Assembly Instructions Connecting pistons Warning: Two people will be required! With the ottoman frame fully supported in the Nut pre-assembled raised position, connect the loose end of the pistons to hinges , using the nuts that are pre-assembled onto the hinges.
