Arlo 3 Drawer Wardrobe White-Pine
Assembly Instructions
8791335
- Please keep for future reference
Dimensions
Length - 78cm
Depth - 53cm
Height - 180cm
Weight - 67kg
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@fl exa.dk
Issue 1 - 26/11/18
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Home Arlo 3
Summary of Contents for Argos Home Arlo 3
- Page 1 Arlo 3 Drawer Wardrobe White-Pine Assembly Instructions 8791335 - Please keep for future reference Dimensions Length - 78cm Depth - 53cm Height - 180cm Weight - 67kg Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 or e-mail: order@fl...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • We do not • Check you have all the • Do not stand or put weight on recommend the components and tools listed on the product, this could cause use of power pages 2, 3 and 4. -
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: 0045 7668 8055 Please check you have all the parts listed below Top x1 Base x1 Shelf x2 (78.0x53.0x1.6cm) (78.0x53.0x1.6cm) (74.8x50.2x1.6cm) No. 4301-1607803-40 No. 4301-1607804-40 No. 4301-1607486-40 Plinth side x2 Leg x4 Plinth front x2... - Page 4 Components - Parts If you have damaged or missing components, call the Customer Helpline: 0045 7668 8055 Please check you have all the parts listed below Door x2 Back panel x1 (105.8x37x1.6cm) (164.7x76.6x0.3cm) No. 4301-1610581-40 No. 4309-0316471 Side panel Right x1 Side panel Left x1 (162.8x52.6x1.6cm) (162.8x52.6x1.6cm)
- Page 5 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. No. 4020-005 No. 3933-15010 No.
- Page 6 Assembly Instructions Step 1 Screw the threaded bushes into the leg using 6mm allen key so that they are fl ush with the leg. Screw the connecting bolts into the threaded bushes Repeat for 4 legs. Step 2 Insert the dowels into the holes in the plinth fronts...
- Page 7 Assembly Instructions Step 4 Attach the assembled plinth to the base with the chipboard screws NB! Align the holes in plinth sides with the small holes in base 6 HOLES UP! Step 5 Attach minifi x bolts to the top and to the base Attach magnetic catches...
- Page 8 Assembly Instructions Step 7 Insert the dowels the holes in the side panels Attach minifi x bolts Front edge the side panels Attach the hanging rail fi ttings to the side panels with screws Attach the hinge mounting plates to the side panels Attach the drawer runners...
- Page 9 Assembly Instructions Step 8 Attach the side panels to the shelfs with the minifi x cams Be aware of the front edges! Step 9 Attach the top the base to the side panels with the minifi x cams Be aware of the front edges!
- Page 10 Assembly Instructions Step 10 Attach the back panel 606 mm with nails to the back side of the wardrobe. Nail the back panel the carcass around the edge ensuring that there are NO GAPS between the top and the back panel .
- Page 11 Assembly Instructions Step 12 Insert the dowels into the holes in the drawer sides Attach the minifi x bolts to the drawer front Repeat for all drawer sides and drawer fronts. Step 13 Attach the drawer sides to the drawer front with the minifi...
- Page 12 Assembly Instructions Step 15 Measure out the positions for the wall attachment straps. Drill two holes spaced as illustrated with the appropriate size for the wall attachment fi tting (see next step). Pull the two straps through the gaps in top plate .Push the furniture against the wall...
- Page 13 Assembly Instructions Step 17 Place the assembled drawer between the drawer runners Attach the drawer sides to the runners using the screws Repeat for all drawers. Place the hanging rail into the hanging rail fi ttings Attach the doors with the hinges to the mounting plates...
