Fig. 1
CAUTION: De-energize unit prior to servicing.
For continued protection against risk of electric shock and fire hazard replace fuse with the same type and rating.
Do not expose to rain or moisture.
Earth Ground
115VAC
power
mains
non power-
limited
Class 1
AC Delay
Battery connection
non power-limited
Battery 1
AL400UL3 / AL400UL3X Installation Guide
+ DC –
+ BAT –
ON
Battery 2
5VDC
12VDC
24VDC
- 5 -
