Technical Specifications - Circutor DH96-CPP Manual

Auxiliary supply:
Rated value:
Frequency range:
Burden:
Display :
Input circuit:
Free contact:
TTL / 24V:
NPN or PNP sensor:
Isolation:
Between the input circuit, the measuring circuit and the output measure-relay, RS 485 /232
Test voltage:
Pulses test:
Environmental conditions
Storage temperature:
Operation temperature:
General characteristics
Dimensions:
Weight:
Case material:
Protection degree:
Relays features :
Rated A.C. current :
Maximum A.C. current:
Maximum resistance load:
Isolation resistance 500 V:
Contact-coil isolation:
Contact-contact isolation:
Mechanical endurance:
Electrical endurance:
Design standards:
IEC 1010 / IEC 348 / IEC 664 / EN50081-2 / EN50082-2 /ANSI C12.5-1978/ UL508/
C22.2 No 14 / VDE0435

Technical specifications

Vc
Rc
Rc
Logic Level 0
Logic Level 1
Rc
Logic Level 0
Logic Level 1
:
:
115V or 230 V a.c. / 24 or 48 V a.c.
(-15 %, +20 %)
45 to 65 Hz
4 VA (without optional card)
7 VA (maximum burden)
7 segments
14 mm high 4 digits
Hi-efficacy red colour
Overrange indication "----"
8 indication LED
Programmable decimal point
5 V
W
3,9 k
W
47 k
< 2 V
> 3 V
W
2 k
< 2 V
> 3 V
3 kV RMS 50 Hz during 1 min
4 kV (1.2/50 µs)
-40 ºC to +70 ºC
-10 ºC to +65 ºC
96 x 48 x 138 mm
550 g
ABS V0, anthracite grey
Frontal: IP 54
IP 65 with frontal protect
Case: IP 20
Terminal: IP20
1 single contact
5 A
250 V a.c. 50 Hz
750 VA
W
> 1000 M
2000 V c.a.
750 V c.a.
> 20.000.000 operations.
> 30.000 operations at 5 A. and 250 V
Page 3
