(b) To turn the auto shutter off, select
"Shutter" from the "Options Menu".
"ON" should flash next to the word
"Shutter". Press the down button.
"OFF" should now flash. Press the
"White Balance" (Select) button. A
"Shutter Off" message will display.
Pressing the "Presets" (menu/exit)
button will save the change.
(c) To turn the auto shutter on, select
"Shutter" from the "Options Menu".
"OFF" should flash next to the word
"Shutter". Press the up button. "ON"
should now flash. Press the "White
Balance" (Select) button. A "Shutter
On" message will display. Pressing the
"Presets" (menu/exit) button will save
the change.
NOTE: Auto shutter default at start-up is
On.

2.1.6.2 Presets Menu

The "Presets Menu" allows users to customize
the Presets that can be accessed via the camera
controller's front panel, and to determine what
Preset will be active at start up.
Preset 1 Enhancement
Preset 2
Preset 3
Brightness
Preset 4
Preset Wakeup
1. To select the appropriate Preset, select "Pre-
set"; "1", "2", "3" or "4" will appear on the
monitor. Use the "up arrow" or "down
arrow" button to scroll through until the
appropriate Preset is flashing. Press the
"White Balance" (Select) button. The user
can now adjust the enhancement level,
brightness level, window size and gain.
(a) Increasing enhancement improves and
accentuates fine details in the picture.
Decreasing enhancement softens the
edges of an object.
(b) The brightness can be adjusted by the
user to obtain the appropriate
brightness level for optimal picture
quality.
17
Presets Menu
4
75
Window Size-Large
Gain-Low
