Adjusting Brightness

2.1.3.1 Using the Camera Controller

1. To adjust the image brightness, perform the
following:
(a) Press the up or down button under
"Brightness" to display the "Brightness
Level" adjustment screen.
Brightness - 75
Dark
(b) To make the image brighter, press the
up button. The cursor will move to the
right with each press until maximum
brightness is obtained.
(c) To make the image darker, press the
down button. The cursor will move to
the left with each press until minimum
brightness is obtained.
The "Brightness Level" adjustment screen dis-
appears after a few seconds when no further
action is taken.
NOTE: Brightness default at start-up is
determined by the configuration of the
camera controller in the Options Menu
(See "2.1.6.1 Options Menu" on page 16).

2.1.3.2 Using the Camera Head Buttons

The brightness level can also be adjusted via the
camera head buttons. In order to adjust the
brightness level using the camera head buttons,
the camera head button must be programmed
properly in the Options Menu (see "2.1.6.3
Camera Head Button Menu" on page 18 ).
1. To adjust the image brightness, perform the
following:
(a) Press and hold the camera head button
(b) To make the image brighter, press
Bright
(c) To make the image darker, press
The "Brightness Level" adjustment screen dis-
appears after a few seconds when no further
action is taken.
NOTE: Brightness default at start-up is
determined by the configuration of the
camera controller in the Options Menu
(See "2.1.6.1 Options Menu" on page 16).
14
that is programmed for brightness con-
trol (either button 1 or button 2). The
"Brightness Level" adjustment screen
will display.
camera head button 1. The cursor will
move to the right with each press until
maximum brightness is obtained.
camera head button 2. The cursor will
move to the left with each press until
minimum brightness is obtained.
